Newest Disco Ball Magicdot-R 60W LED Moving Head Light
Specific Parameters:
OPTICS
Beam aperture: 4,5°
85% optic efficiency
High-efficiency 94 mm PMMA optics
LIGHT SOURCE
1 multi-chip 60 Watt LED source
Light output: up to 1,800 lumen
Luminous intensity: 180,000 cd
Rated sources life: up to 50,000 hours
Flicker free sources management, suitable for TV
applications and all video recorded events
MOVEMENT
Continuous PAN and TILT rotation
Extremely accurate positioning
Moving-head operated via either 8 or 16 bit
resolution
High-resolution stepper motors operated via
microprocessors ensure extreme accuracy and
smooth movements.
PAN and TILT automatic repositioning
COLOURS
Sophisticated 4 colours RGBW mixed, reaching high Colour Rendering Index
Uniform light beam with no colour shadows, and rich saturated and pastel colour-hues
4.29 billion colours (8 bit resolution)
Virtual colour wheel, including most usuals white
colour temperature presets
Dynamic colour macro effect with variable speed
DIMMER / STROBE
Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second
SOFTWARE FACILITIES
Local DMX addressing of the luminaire and its optional parameters through its built-in LCD panel control
Remote DMX addressing of the luminaire and its optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software version
POWER SUPPLY
Electronic supply with active PFC
110 to 240 Volts - 50/60Hz
Power 130 Watt max
COOLING SYSTEM
Advanced cooling system based on heatpipe technology
Self adjusting variable speed fans for quiet operation (Auto mode)
Selectable auto, stage & studio ventilation modes
Safety protection against temperatures excesses
HOUSING
Moving-head skeleton made of aluminium and steel metal plates
Heatsinks in aluminium and copper, satin finish
Moulded covers in self-extinguishing fire retardant
ABS PC (V0 class)
Two sides handles for transportation IP20 protection rating
Exterior finish: black (Carbon)
INSTALLATION
Fastening brackets system: one Omega 1
4 turn brackets designed for use with standard clamps
Mounting points: two 1
4 turn locking fittings allowing
installation of Omega bracket on luminaire
Safety cable attachment point
OPERATING PARAMETERS
Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45°C (113°F)
Minimum permitted ambient temperature (Ta min): -10°C (14°F)
Minimum usage distance: 0.2 m (8 inches)
COMPLIANCE
EU (EMC)
EN 55015 (2006) - EN 55015 A2 (2009)
EN 61547 (2009) - EN 61000-3-2 (2006)
EN 61000-3-2 A2 (2009) - EN 61000-3-3 (2008) EU (LVD)
EN 60598-1 (2008) - EN 60598-2-17 (1989)
EN 60598-2-17 A2 (1991)
SIZE
Product:210x318x210mm(lxhxd)
Flight-casefoam:251x330x251mm(lxhxd)
WEIGHT
Product: 5.3 KG
PRODUCT CODES
015150: MAGIDOT-R CREATIVE SOLUTION
HARDWARE FACILITIES
Graphic LCD display for addressing and special functions settings, with flip function
6 menu buttons to set the functions
Over temperature protection
XLR 5 pin male and female connectors for DMX
connection
PowerCON TRUE1 male and female connectors for
power connection
CONTROL
DMX 512 protocol, through DMX cable
DMX-RDM compatible
Stand-alone mode and Master/Slave modes
Local control panel, with LCD display
Choice of 2 DMX modes (from 14 to 16 DMX
channels)
