Moving Head
1. Moving head light manufacture
2. CE, RoHS moving head
3. Italy CMYK glass
4. Philips 1200W lamp
5. DMX512, original 32 channel
Moving Head
Source
Lamp
1200W short arc discharge
Base
G-22
Approved model
MSR 1200 SA
Wiring options
208/230/250V, 50Hz; 208/230V, 60Hz
Power consumption
1500W at 220V/50Hz
Mechanical Specification
Height
1070 mm (head in horizontal position)
Width
620 mm
Depth
680 mm
Net weight
50 kg
Gross weight
80 kg (with flycase)
Moving Head Thermal
Maximum ambient temperature (Ta): 40 C (104)
Maximum surface temperature: 135C (275 F)
Gobos
Outside diameter: 37, 5 +0/-0, 25mm
Image diameter: 31, 5mm
Thickness: 1, 1mm up to 6mm in rotating slots
Material: High-temperature Borofloat glass
Prisms and Effects
Outside diameter: 47 +0/-0, 3 mm
Thickness: Up to 5mm in rotating slots (up to 8mm in the center) Control
Moving head Programming
Protocol: USITT DMX-512
Control channels: 24 or 32
Display: Blue/white LCD graphic
Pan/Tilt resolution: 8- or 16-bit
Gobo indexing: 8- or 16-bit
Prism indexing: 8- or 16-bit
Data in/out: Locking 3-pin & 5-pin XLR
Electromechanical Effects
Cyan: 0 - 100%
Magenta: 0 - 100%
Yellow: 0 - 100%
CTO: 0 - 100%
Color wheel: 6 replaceable 'SLOT&LOCK' V colors +open Gobo wheel 1: 6 rotating, inflexable, replaceable 'SLOT&LOCK' Gobo wheel 2: 6 rotating, indexable, replaceable 'SLOT&LOCK' Gobo dimension: Gobo size: 37.3mm picture size: 31.5mm
Iris: Motorized, stepless
Effect wheel: 4 rotating, indexable, replaceable 'SLOT&LOCK'
Frost effect: Separate, variable
Dimmer/Shutter: Full range dimming and variable strobo effect
Focus: 2m - infinity
Zoom: 13° - 42°
Pan: 530°
Tilt: 280°
Rigging
Mounting points: 8 pairs of 1/4-turn locks
Fixation option: Pan/Tilt-lock mechanism
CHANNEL
CH1 PAN
CH2 PAN 16BIT
CH3 TILT
CH4 TILT 16BIT
CH5 PAN/TILT SPEED
CH6 SPECIAL FUNCTION
CH7 PAN/TILT MACRO FUNCTION
CH8 PAN/TILT MACRO SPEED
CH9 COLOR WHEEL
CH11 MAGENTA
CH12 YELLOW
CH13 CTC
CH14 CMY MACRO
CH15 EFFECT SPEED
CH16 EFFECT SPEED ASSIGNING
CH17 GOBO 1
CH18 GOBO 1 ROTATION
CH19 GOBO 16BIT
CH20 GOBO 2
CH21 GOBO 2 ROTATION
CH22 GOBO 16 BIT
CH23 PRISM
CH24 PRISM ROTATION
CH25 PRISM 16BIT
CH26 FROST
CH27 IRIS
CH28 ZOOM
CH29 FOCUS
CH30 STROBE
CH31 DIMMER
CH32 DIMMER 16Bit
