Home LED Light Products Modular Design Ik10 Shockproof High Bay LED Industrial Light

Modular Design Ik10 Shockproof High Bay LED Industrial Light

Modular Design Ik10 Shockproof High Bay LED Industrial Light
Price: US $ 196.53-209.27/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
Modular Design IK10 Shockproof High Bay Led Industrial Light

Main Features:
1. Wide Power range: 40W to 400W
2. Input Voltage: 90-305VAC, 277-528VAC, DC12V/24V
3. Long Lifespan, TM21 reported L70>62000hours
4. Philips LumiLEDs, 110-120lm/w
5. Meanwell driver, IP65 and IP67 optional
6. Warranty of LED Flood Light: 8 years
7. UL cUL DLC, TUV GS CE RoHS, CB, SAA, TM21, IK10 listed
8. Short production time: 5-7 working day

Application of High Bay Led Industrial Light
1. Warehouse Lighting, Factory Lighting, Industrial Lighting
2. Garage Lighting, Workshop Lighting
3. Outdoor Area Lighting, High Mast Lighting, Stadium Light
4. Supermarket Lighting, Store Lighting
5. Tunnel Lighting, Bridge Lighting
6. Gas Station Lighting

High Bay Led Industrial Light Spec.:

 Driver   Meanwell Driver
LED High Bay Light Chips   Philips Luxeon T chip
Operating Voltage   90-305VAC, 50/60Hz
Operating Temperature  -40 ºC to +50 ºC
Operating Humidity   10% to 90%
Power Fact    >95%
Power supply efficiency    >90%
Initial Luminous Flux   12000LM
Maintain Luminous Flux   13200LM
LED Luminous Efficiency   105-110lm/w
CRI    Ra > 70 (>80 optional)
IP Rating    IP65 & IP67
Guarantee    8 Years Warranty
Color Temperature    3000K-6500K
Heat Radiator    Anodized Aluninum
Face   Anti-static Coating
Fixture Dimensions     304*311*196mm (11.9*12.2*7.7 inches)
Fixture Weight       7.3kg
CertificationsCE, RoHS, TUV, UL, SAA, DLC CB

Parameters of  High Bay Led Industrial Light:

Item No.Power
LED QtyModule
Junction Temp
Max Current

Different Li ght Distributions of High Bay Led Industrial Light
For Different application requirement, AOK customised different types of beam angles for customers, at the moment we have 60°, 90*100°, 120° beam angle available.

Certificates of
High Bay Led Industrial Light:

1. UL Certificate No.: E364473
2. TUV GS-Mark Approval, Certificate No. S 50277285
3. CB TEST CERTIFICATE, Ref. Certif. No.: DE 2-017520
4. SAA Certificate No.: TUV01877E
5.  For DLC, please check in website: www.designlights.org/QPL#results, search by keyword "AOK" for more details of interested items.

Packaging & Shipping of High Bay Led Industrial Light
1. Standard export Carton Box, 1unit/ carton
2. Pallet packing for bulk orders, 30 to 40 units/ pallet
3. Container loading for large orders.
Strict Quality Control System for High Bay Led Industrial Light

ISO9001:2008 Quality control system

Complete & strict quality control system from incoming material quality control, procession quality control to ready prodcut quality control.

High Quality Manufacturer authorized by UL organization.

Best Partner of Philips Lumileds from 2013~2014, 2014~2015

More Company Introduction

AOK is a leading manufacturer of Outdoor and Industrial LED lighting products in China.

Main products: LED High Bay Light, LED Flood Light, LED Tunnel Light, LED Gas Station Canopy Light, LED Street Light etc with 8 years warranty.

AOK service


1. Before and after sales in time service 7/24.

2. Professional Lighting solution suggestions, dialux simulation available.

3. Payment terms: Paypal, TT, LC, DP etc.

4. Trade terms: EXW, FOB, CIF, CFR

5. Short Lead time: 5-7 working days for sample order and orders less than 100units.

6. NO MOQ required, sample testing welcome.

AOK LED Light Company Limited
Contact: Joney Jiang      Mobile: +86-15960023989
Website:  www.aokledlight.com
Address: 5 Blding, No 150, MinJiang Road, CangShan Zone, Fuzhou City, China. Zip: 350008

Prod Model: AOK-160Wi
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
150W 160W LED High Bay Light LED Driver: Mean Well
Working Lifetime(Hour): 62, 000
Warranty(Years): 8
Replace HID /HPS / Metal Halide Lamp: 400W
Options: Dimming/Timer/Zigbee/Dali/Photocell/Motion Sensor
Product Name: High Bay LED Industrial Light
Lamp Body Material: Aluminum Alloy
IP Rating: IP67
Certification: UL
Color Temperature: 3000k, 3500k, 4000k, 5000k, 5700k, 6500k
Color: Black, Silver, White
Power: 160W
Usage: Warehouse, Tunnel, Stadium, Gas Station;Airport
Lifespan: 62, 000
Beam Angle: 30°, 60°, 90*100°, 120°
Fuzhou AOK LED Light Co., Ltd is an enterprise specializes in the manufacture of LED Outdoor Light.

Here as below are our main products:

1. LED Street light (Solar LED Street Light)

2. LED Flood light

3. LED High Bay/Low Bay Light

3. LED Canopy Light

4. LED Tunnel Light

5. LED Area Light

6. LED Parking Lot Light

With ISO09001-ISO14000 Quality control system, now most of our products get CE, RoHS, UL, DLC, TUV, SAA certificate, we supply you more than 5-8 years warranty for most of products.

Meanwhile, OEM is also welcomed.

In view of our reliable quality, competitive price, on-time delivery and excellent services, our clients keep long-term and good business relationships with us, most of them are returned customers from over 100 countries. Our turnover grows constantly every year. In the recent years, we have expanded to become a large group company, possessing three plants and a big warehouse and quality laboratory at our headquarters. There are totally over 400 workers in our factory which covers an area of 25, 000 square meters.

Adhering to the company principle of "quality first", we have set up a strict quality control and assurance system, and most of our products have acquired CE, RoHS, UL, VDE, SASO certificate to meet different markets requirement. Meanwhile, in order to increase customers' satisfactory degrees, we have established a mature after-sales service system. We are working to provide high quality products with excellent services and prompt delivery to our clients.

We are sure that our high quality products and excellent service will attract more and more customer appreciation. Contacting us is the first step to build up a successful business relationship with us. If you are interested in any of our products, please feel free to visit our website or contact us directly for more information. We look forward to cooperating with you in the near future
