Fast install,Wide viewing, Level Surface, More Durable, Good Quality.
could be used in outdoor environment such as cultural or relax square, commercial walking street, residential sub-district, downtown, etc.
Huasun LED display screen indoor for indoor/outdoor stage, exhibition center, night club and outdoor Concert & Performance, music club use. Soft and flexible LED video display make all the indoor events become more colorful & lively.
Features:
IP65 ingress protection on front and rear,totally suitable for outdoor application.
Excellent light,weights under 8.5kg/.Small volume,easy transportation
High power LED lights are available in each module.Show double effects on screen
Specifications
Model No | Mesh-50 | Lighting |
|
Pixel pitch | 50 | 200 |
|
Density | 400 | 25 |
|
Pixel configuration | RGB 3-IN-1 SMD LED | RGBY 4-IN-1 SMD LED |
|
Brightness(White) | 1800 | 77LM RGB |
|
Optima visual distance | 50 | 200 |
|
Max.power consumption | 120 | 90 |
|
Average.power consumption | 40W/ | 45W/ |
|
Transparent rate | 46% | 46% |
|
Recommendation size (Size can be customized) | W=200mm L=4800mm(9600mm) T=16 | W=200mm L=4800mm(9600mm) T=16 |
|
|
Weight | 8.5Kg | 8.5Kg |
|
Work voltage | DC 24V | DC 24V |
|
Brightness level | 16 levels |
|
|
Bit depth per color | 16 bit | 16 bit |
|
Bit depth per pixel | 48 bit |
|
|
Visual angle | Horizontal:120°; Vertical:120° | Horizontal:120°; Vertical:120° |
|
Refresh rate | Static |
|
|
Display mode | 1280X1024 | 1280X1024 |
|
Drive mode | Constant current | Constant current |
|
Signal type | AV,S-Video,VGA,CVBS,HDMI,DVI | AV,S-Video,VGA,CVBS,HDMI,DVI |
|
Operating system | Windows2000/XP/Vista/Window7 | Windows2000/XP/Vista/Window7 |
|
Control distance | HSYV;<100m | HSYV;<100m |
|
Ingress protection | IP65 | IP65 |
|
Ambient temperature | -20~+50ºC | -20~+50ºC |
|
Relative humidity | 10%~90% | 10%~90% |
|
Power system | Power-1000,Power-2000,Power syste | Power-1000,Power-2000,Power syste |
|
After-Sale Service
1. Warranty: 1 Years. Lifetime free maintenance and upgrade.
2. Free reserve part
3. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
4. Free technician training.
Huasun Technology Co., Ltd. is a high-tech enterprise that is engaged in the researching, developing, producing, marketing, and engineer service of LED display and LED lighting. It has been grown in Beijing, capital of China, for over ten years. The main products and services include LED display system, LED digital stage system, LED lighting system. With a business principle of technological innovation and professional service, the company commits to provide high-quality LED products and solutions for all clients.
The company has a R&D team made up of senior engineers. Taking advantage of the technological and cultural resource in the Capital of China, working together with experts in mechanism, optics, and electronics from the main universities, the team is devoted to the research and application of multimedia technology and has gained the leading position in product design, software development, mechanical design and optical application. The company has own many national invention patents in LED display technology. Flexible LED display, one of our patents, is a landmark product in the development of LED display. It is widely used by the clients from all over the world for the advantages of compact size, light weight, and easy installation. We always keep in mind that the mission and responsibility of the enterprise is to change the world by pioneer spirit and innovative product in a technology high speed age. We are always proud of it.
Welcome to future of Huasun: A brighten future.
