Martin Viper CMY 15r 330W Stage Moving Head Light
Youtube Demo: https://youtu.be/EkwBvKV1Xew
Power Supply: 100~240V AC, 50/60Hz (E-ballast)
Power Consumption: 450W
Light Source: PHILIPS 15R (OSRAM SIRIUS HRI 330W 7500k / YODN 15R optional)
Optical System: 3-lens group, high efficiency reflector, zoom 5 degree.
Colors: CMY Color Mixing System;6 color plus white. Variable speeds and bi-directional rainbow effect.
Rotating Gobos:8 rotating Martin Viper Spot Gobos+ white.
Fixed Gobos: 1 rotating gobo wheel with 14 fixed gobos+ white.
Prism/Frost: 3-facet rotating Prism + Frost Filter
0~100% linear frost
Beam angle: 0°~5°, Linear zoom
Dimmer: 0~100% linear dimmer, Double strobe/shutter blades, multi-strobe function
Head movement: Pan 540º, Tilt 270º with auto position correction,Pan/Tilt fine function, 8 bit /16 bit
Control: International standard DMX512 signal, 5 pin interfaces. 21/23/34channels, Self-test mode LCD touching display, word-inverted function Physical Features: Housing Composite plastic (IP20)
Net Weight 21.5Kg. Packing: Carton/Double flightcase
Channel | Function |
| CH1 | Pan |
| CH2 | Tilt |
| CH3 | Pan fine |
| CH4 | Tilt fine |
| CH5 | Pan/tilt speed |
| CH6 | Dimmer |
| CH7 | Strobe |
| CH8 | Atomization |
| CH9 | Color |
| CH10 | Color speed |
| CH11 | Gobo |
| CH12 | Gobo speed |
| CH13 | Prism |
| CH14 | Prism rotation |
| CH15 | Prism amplification |
| CH16 | Focus |
| CH17 | Lamp on/off |
| CH18 | Reset |
| CH19 | Dimmer, prism, frost speed |
| CH20 | No function
|
