Features:
1) Various colors including single color and RGB colors;
2) Can do waterproof or Non-waterproof;
3) 5m/reel for standard length, different length available;
4) Solid-state, high shock / vibration resistant;
5) Viewing angle is 120 degrees and the working voltage is DC12V;
6) Maintenance free, easy installation;
7) Long life 100, 000hrs+ (10+ years), white LED, 50, 000hrs+
8) Low price, quantity production, short lead time
Applications:
1) architectural decorative lighting
2) accent lighting
3) border/contour lighting
4) emergency&security lighting
5) Auditorium walkway lighting
6) Stairway accent lighting
7) Concealed lighting
8) Backlighting for signage letters
9) Channel letter lighting
10) Cove lighting
Basic technical data:
1) Standard length: 5 meters/reel
2) Ribbon width: Single color 10mm, RGB tri-color 10mm
3) Printed circuit board thickness: Single color 0.25mm, RGB tri-color 0.2mm
4) Working voltage: DC12V
5) Working current: Single color 2A, RGB tri-color 3A
6) Entire ribbon LED quantity: Single color 300PCS, RGB tri-color 150PCS
7) Size of smallest 3-LED unit (L x W): Single color 50 x 12mm, RGB tri-color 100X 14.5mm
|
Item No. |
LED Color |
Voltage |
Current |
Power |
LED Qty |
LED warelengt(nm)
Color Temperature |
Lumen |
Bean Angle |
|
OML-3528-R |
R |
12V |
0.02A |
2.4/4.8W/M |
30/60 |
620-630 |
90 |
120° |
|
OML-3528-Y |
Y |
12V |
0.02A |
2.4/4.8W/M |
30/60 |
590-595 |
240 |
120° |
|
OML-3528-B |
B |
12V |
0.02A |
2.4/4.8W/M |
30/60 |
465-470 |
60 |
120° |
|
OML-3528-G |
G |
12V |
0.02A |
2.4/4.8W/M |
30/60 |
520-525 |
90 |
120° |
|
OML-3528-W |
W |
12V |
0.02A |
2.4/4.8W/M |
30/60 |
6000-6500 |
360 |
120° |
|
OML-3528-WW |
WW |
12V |
0.02A |
2.4/4.8W/M |
30/60 |
2800-3200 |
300 |
120° |
