HYE Series Solar-Wind hybrid streetlight is an intelligent, off-grid LED street light system. Composed of solar modules and wind turbine, PV deep cycle batteries, controller and a LED streetlight, this hybrid streetlight takes solar/wind as energy source and utilizes the energy for the lighting automatically during the night.
The Hybrid LED Street Light is a remarkable stand-alone street light which produces and stores the power it harvested from wind and sun. No underground wires or trenching required.
Advantage of wind-solar hybrid street light
A. Generating power day and night
B. Balance seasonal power output difference of wind and solar
C. Independent system, no city grid cable needed
D. Longer battery life
E. Easy installation, simple operation, applicable in majority of roads
F. Intelligent lighting control system, maintenance free
Major Applications
A. Highway
B. City main road
C. School campus road
D. Sidewalk
E. Pathway
F. Farm & ranches lighting
G. Villa lighting
H. Landscape lighting - park, square etc.
System Design
HY Energy has various kind of wind-solar hybrid lighting system designed for various load capacity and natural resources condition, the hybrid system requires precise calculation and design according to application, street road condition, terrain etc. Otherwise the system will have problem such as inefficient lighting, complete no power in raining season or even safety issue. Please send us your load capacity and application range via email, we will quote you with a clear custom designed solution accordingly.
Technical Support & Services
A. Custom design - base on light source load, lighting hours, site wind & solar resources condition
B. Detailed installation guide or optional on-site technician guidance
C. Remote system operation monitoring - operating stage
D. Warranty on major parts - warranty & replacement
Standard Solution
For your reference, please send enquiry to us directly, we will design the whole system accordingly. - The best quality wind solar street lighting system is always the most fitable design and also good quality parts! ! !
Product keywords: LED street, LED street lighting, LED street lamp, LED road lamp, LED lighting system, Wind Solar Hybrid Street Light LED, wind solar hybrid street lamp LED, wind solar hybrid street lighting, LED street light, LED street lamp, LED street lighting, wind solar LED street light, solar street light LED, solar street lamp LED, road light, solar road light, road lamp, street light wind generator, wind solar hybrid power, solar LED street lighting
|
Components |
Model No. |
Specification |
qty |
|
Wind generator |
HY-400L 24V |
400W 24V, 5 blades low wind type |
1 |
|
Solar panel |
90W 12V |
120W polycrystalline solar modules |
2 |
|
Wind & solar hybrid controller |
WWS06A-24 |
400W 24V hybrid charge PWM controller with Low voltage charging module |
1 |
|
LED lamp |
90W 24V |
90W, DC24V, life span over 50, 000hrs, first 4 hours work on full power, last 4 hours work on half power |
1 |
|
Battery bank |
150AH 12V |
LEOCH 150AH deep cycled gel battery, maintenance-free |
2 |
|
Lamp post for power system |
HYWSL1.0-8 |
8 meter high hot-dip galvanized steel with 4mm wall thickness, coating thickness 75u ~ 85u, sprayed with plastic powder paint. Lamp height 6 meter, with solar panel bracket, lamp arm and anchors included |
1 |
Guangzhou HY Energy Technology Limited Corp. Is a high-tech enterprise engaged in designing, manufacturing, marketing on highly reliable small wind turbines and serving in wind-solar hybrid power system integration technique.
Guangzhou HY Energy Technology Limited Corp. Has made tremendous contributions to improve national wind generator manufacturing level under the breakthrough technique on wind turbine design conception and production craft since 2001, meanwhile, our breakthrough technique on wind-solar hybrid power system has also LED a large scale application in real circumstance.
HY Energy was appointed to be the drafter of off grid wind solar generating safety requirement standard No. (20074719-T-604) based on the advance technology inaugurator of perfect matching design on wind blade and generator and the perfect matching on wind energy and solar energy.
Guangzhou HY Energy Technology Limited Corp. Is the sole enterprise passing design and manufacture of high reliable small wind turbine project and accepted by The Ministry of Science and Technology of the People' S Republic of China.
HY Energy' S wind turbine series has successfully been selected into WWEA 2010 and WWEA 2011 global high quality small or medium generator catalogue.
