Quick Details
Light Source: LED
Item Type: Spotlights
LED Light Source: COB
Warranty(Years): 5
Input Voltage(V): 85V-265V
Lamp Power(W): 10
Lamp Luminous Flux(lm): 900
Lamp Luminous Efficiency(lm/w): 100
CRI (Ra>): 80
Color Temperature(CCT): Pure White
Working Temperature: -35 - 50
Working Lifetime(Hour): 50000
Lamp Body Material: Aluminum
Certification: CE, EMC, RoHS
Base Type: Wire Connection
Place of Origin: Guangdong, China (Mainland)
Brand Name: YT
Model Number: YT-TK-10W
Driver: Isolated Internal Driver
Dimension: H179*W133*D56MM
Socket Type: Direct Wire Connection
LED Quantity: 1
LED Type: COB
Beam Angle: 100
Color Temperature: 3000K-6500K
Driver IC Manufacturer: Texas Instruments
Capacitor Manufacturer: Rubycon
IP Class: IP65
.
Packaging & Delivery
Packaging Details:
1 Piece LED Spot Light / Retail Box, 40 Pcs / Carton Carton Size: 595*370*450mm Gross Weight: 36KG/Carton
Delivery Detail:
> 3 days
.
Specifications
10W LED Spot Light
COB LED, 900 LM
Isolated Internal Driver
IP65
CE, ROHS certificated
Name
10W LED Spot Light
Model
YT-TK-10W
Size
H179*W133*D56MM
Power Socket
Open Wire Connection
LED Type
COB
LED QTY
1
Luminous Flux
900 lm
Light Effect
85-100 LM/W
Beam Angle
100
Color Temperature
3000K-6500K
Power Factor
>0.95
Power
10W
Driver Type
Isolated Driver
Driver IC
Texas Instruments
Driver Capacitor
Rubycon
Input Voltage
AC85~265V
Power Apply
Wire Connection to AC Electricity
Operation Temperature
-35° C~50° C
CRI
>80
Certification
CE, RoHS
Housing
AL+Tempering glass
LED, Driver, Power, Color Temperature and sizes can be customized
Product Description:
1. Large aluminum base is used for good heat dissipation.
2 It is lightweight and easy for installation.
3. Tempering glass is used whose light transmittance reaches as high as 93%.
4. IC controled Isolated driver makes power efficency high and LED light long lifespan.
5. It saves 85% of the power compared to halogen lamps
6. It's lifespan can reach 50, 000 hours which is 15 times higher than halogen lamps.
7. It's Environmental friendly, no harmfull material like mercury is included.
8. Every single product is tested for 24 hours under different voltage from 85V to 265V and on/off switches
Before shipping to keep failure rate as low as possible.
Other Models in this serial
YT-TK-10W
YT-TK-20W
YT-TK-30W YT-TK-50W YT-TK-70W YT-TK-100W YT-TK-150W YT-TK-200W
Size(mm)
H179*W133
*D56
H201*W166
*D77
H215*W178
*D81
H253*W194
*D95
H291*W250
*D122
H309*W250
*D192
H375*W310
*D187
H400*W340
*D192
Power(w) 10W 20W 30W 50W 70W 100W 150W 200W
LED Chip COB COB COB COB COB COB COB COB
LED QTY
1
1 1 1 1 2 2 4
Luminous
Flux
900lm
1700lm 2700lm 4500lm 6500lm 9000lm 14000lm 18000lm
Capacitor
Rubycon Rubycon Rubycon Rubycon Rubycon Rubycon Rubycon Rubycon
IC
Texas
Instruments
Texas Instruments
Texas Instruments
Texas Instruments
Texas Instruments
Texas Instruments Texas Instruments Texas Instruments
Power Connection
Open wires
Open wires Open wires Open wires Open wires Open wires Open wires Open wires
Color Temp(K)
3000K-6500K
3000K-6500K 3000K-6500K 3000K-6500K 3000K-6500K 3000K-6500K 3000K-6500K 3000K-6500K
Voltage(V) AC85~265V
AC85~265V
AC85~265V
AC85~265V AC85~265V AC85~265V AC85~265V AC85~265V
CRI >80 >80 >80 >80 >80 >80 >80 >80
