1. Material:
Aluminum Alloy Housing
Frosted Glass Cover
Processed Surface and Spray Painted
2. Standard Specifications:
Beam Angle: 130° Cool White: 5000~6000K 90~260V/AC
3. Optional Parts:
Beam Angle: 80° / 40° Warm White: 3000~4000K 12/24V/DC
Above may be changed with standard part to fit the specification required for your unique project.
4. Application: Retail Stores, Office, Hospitals, Bathrooms, Houses, Supermarkets.
Warranty: 2 Years
RoHS
|
CE
|
Safty Class11
|
IP 40
|
50Hz~60Hz
|
Protection Class 2
|
Recyclable
|
Item
NO.
|
Input(V/AC)
|
Power(w)
|
Luminous flux(lm)
|
Color temperature(K)
|
Color rendering index(Ra)
|
Size (mm)
|
SP7000
|
90~260
|
7
|
560
|
5000~6000
|
80
|
¢ 188*156
(Drilling size¢ 170mm )
|
SP7001
|
9
|
720
|
¢ 218*156
(Drilling size ¢ 190mm )
|
