Product Description
1. Description:
Promotion on June for new generation of LED Panel light.
All with Samsung super high brightness LED and Meanwell driver.
Light Efficiency: >95lm/w
CRI: >80
Warranty: 3years
Certificate: CE&RoHS
2. Advantage:
>Easy installation: Simply replace the grill lamp or false ceiling, or hang from the roof using chains
>Simple, artistic and splendid, functions at both lighting and art decoration
>Super Slim of 11.5mm thickness, making for attractive and versatile signage
>Edgewise, the LEDs emit evenly lighting through a LGP (ACRYLIC), the luminosity is bright, soft and comfortable for eyes
> Cooler than traditional displays, versatile in size, shape and configuration.
> Four sides illuminating, better heat sink, with temperature rise less than 20 deg, good for extending the panel lifespan
> Optimized circuit design ensures no interference with any other LEDs when a single one fails
3. Features
>>Edgelite, the LEDs emit evenly lighting through a LGP(ACRYLIC), the luminosity is bright, soft and comfortable for eyes
>>0.3W SMD LED from Samsung Korea with superb features
>>Ultra slim and light, with thickness only 11.5mm
>>Reliable Meanwell driver from Taiwan with high quality
>>Distinguish circuit design ensures no interference with any LEDs when a single one malfunctions
>>External high PF constant current LED driver, instant start; No filckering and no humming; Safe and reliable
>>Four sides illuminating, better heat sink, with temperature rise less than 20 deg., good for extending the panel lifespan
>>Easy installation: Simply replace the grill lamp or false ceiling, or hang from the roof using chains
>>Aluminum plate for dissipation with coefficient of thermal conductivity more than 1.2;
>>Long lifespan: >=50, 000h; Certification: CE, RoHS
4. Packing
Packing: 1× Panel per Inner box
4× Panel per Outer Carton
5. Applications
LED panel lights are used in ceilings, walls, art gallery, the car, the counter, etc.
|
Model: |
IL-PL3030P22 |
|
Size: |
295*295*11.5mm |
|
LED Specs: |
SAMSUNG SMD5630 |
|
LED Qty: |
48PCS |
|
LED Placed: |
2 sides edge lighting |
|
LED Power: |
19.2W |
|
Fixture Power: |
22W±1 |
|
Input Current: |
0.48A constant current |
|
Working Voltage: |
DC30-42V |
|
CRI: |
Ra≥80 |
|
Luminance: |
1300-1450lm@4000K, 5000K, 5700K, 6500K |
|
|
1200-1300lm@3000K |
|
Net Weight: |
1.8KG |
|
Certificates: |
CE, RoHS, FCC |
|
Installation |
Ö Recessed |
Material |
Aluminum frame& back cover :6063-T5 |
|
|
Ö Ceiling mounted ( needs accessories) |
|
LGP: PMMA |
|
|
Ö Suspending(needs accessories) |
|
Diffuser: PS |
|
Driver |
|
Model: |
ILD-042048 |
|
Input voltage: |
AC100-240V |
|
Frequency: |
50/60Hz |
|
Output current: |
0.48A constant current |
|
Output voltage: |
DC30~42V |
|
PF: |
>0.9 |
|
Efficiency: |
>85% |
|
Net weight: |
0.3KG |
|
Certificates: |
CE, RoHS,FCC |
|
Package |
|
1pc/inner box (driver included),10pcs/outer box,20KG/outer box |
Shenzhen IKES Lighting Co., Ltd. Has been established on the January 06, 2009, Located in Fuyong District Shenzhen, the factory space is 3500 square meters with 224 people here, there are 18 professional engineers also.
We are a professional manufacturer of LED lamps. Our mainly products are LED Tube, LED strip light, LED Moduel, LED spot lights, LED bulbs, LED ceiling lights, LED flood lights, etc, which are widely used in urban lighting decoration, home and hotel decoration, and commercial lighting area. Advanced and professional equipments are utilized to aid LED assemblies of LED strips and various luminaire. The equipments include SMTassembly, auto soldering lines, opto-electrical test devices, light and optical distribution analysis devices. The well trained production and QC staff can assure all the lights perfect performance. All the products are CE certified and RoHS compliant. OEM&ODM are highly welcomed!
