LED Effect Beam Moving Head PAR Stage Disco Light
Product description:
LED Effect Beam Moving Head PAR Stage Disco Light has strong beams , appearance design is compact and light ,good color
mixing with high output lumens , full-featured ,high speed ,super stable safety of PFC power and Optical
System with integrated LENS . competitive price with high quality and easy to transportation and installation .
Application field : Professional stage , ktv , club , bar , concert , theatre , party ,wedding , performance and entertainments places etc .
Features :
The par can zoom light have Extremely small, fast and powerful LED moving beam.
Par zoom can light controled by DMX Channels : 13Channel
Smooth electronic dimming : 0-100%
Have Wide zoom angle with 25-45 degree
The LCD display on the control panel
Electronic strobe with pluse and random effects
High efficiency , low power consumption
Super compact , low weight
Technical parameters :
Input Voltage : AC 100V~240V, 50HZ / 60Hz
Power Consumption : 400W
Light Source : 36pcs x 10W RGBW 4-in-1 led
LED Lighting source : RGBW 4 -in -1
Control Mode : DMX 512 , Master-Slave , Sound Active, Auto Run
Channel : 13 Channel DMX channel
Zoom Angle : 25- 45 degree
Lens : Highly efficient lens system
Dimming : 0-100% dimming
Strobe : 0-20 times /second
Protection grade : IP20
Housing : High-temperature plastic , Aluminium Alloy
Display screen : LCD Display
Working environment : Indoor
Dimension : 304 x 267 x 167 mm
Weight : 5.7 kg
Delivery time :
Sample order , need 3-5 working days after receive the payment , the formal order , need 10-15 working days after receive the deposit .
Payment term :
T/T , 30% deposit , 70% balance before delivery
Packing : Carton or Flight case ( Flight case need to buy )
Shipping Way :
- All the items will test before dispacth to ensure the item arrived in a good condition.
-We will ship by UPS, USPS, Fedex within 2-3 working days after received the payment. (about 2-5 days arrived to your door)
- Also ship by sea, air.
We shall be glad to have your specific enquiry !
13 channel
CH
Value
Functions
1
0~255
Total dimming
2
0~255
Red(when CH8 select PR01~10,CH2 control TIME)
3
0~255
Green(when CH8 select PR01~10,CH3 control FADE)
4
0~255
Blue
5
0~255
White
6
0~5
Invalid
6~20
HIGH POWER(only when in NORMAL POWER model)
21~30
Invalid
31~255
Colorful change (see "Color Selection Table")
7
0~10
Not strobe
11~255
Strobe speed (fastest 255)
8
0~20
Invalid
21~30
Built-in program 1
...
...(Per 10 number on behalf of a program)
110~120
Built-in program 1
121~130
Self program1
...
...(Per 10 number on behalf of a program)
211~220
Self program 10
221~255
Invalid
9
0~255
Internal procedures governor (by ourselves governor please CH2,CH3)
10
0~9
Dimming speed (0 to 9 represents the dimming speed in the SET menu)
10~49
Off
50~99
Speed 1(fastest)
100~149
Speed 2
150~199
Speed 3
200~255
Speed 4(slowest)
11
0~9
ID address invalid
10~19
ID1
...
...(Per 10 number on behalf of a ID)
200~209
ID20
210
ID21
...
...(Per 1 number on behalf of a ID)
255
ID66
12
0~255
zoom
13
0~255
Zoom speed(0 slowest,255 fastest)
