Features:
1. Special design which can make our P10.66 LED panel both front and rear side maintainance accessible. This will greatly cut down the maintain cost.
2. Ultra high brightness (12000 Nit) with low average power consumption (200W/M2).
3. High refresh rate (greater than 1200 Hz) with software adjustable, suitable for filming.
4. High grayscale ( with perfect visual performance.
5. High Contras ratio (2000:1) with black mask and black coating technique.
6. Wide viewing angle (greater than 140 °in horizontal).
7. IP65 protection rating.
8. Fast and easy to assemble and dismantle.
9. High reliability and long lifespan (MTBF ≥ 5000 hours).
Optional for upgrade:
Ultra refresh rate (greater tHighhan 48000 Hz) with software adjustable, suitable for filming
High gray-scale (16bits) with realistic visual performance.
On-site pixel by pixel brightness and color correction bring greater uniformity.
ABOUT HIVISI:
|
P10.66 outdoor full-color LED display |
|
Item |
Details |
Parameters |
|
Pixel |
Physical |
10.66mm |
|
Pixel Configuration |
1R1G1B |
|
Module |
Module resolution |
24*24 pixel |
|
Module Size |
256*256 mm |
|
Cabinet |
Physical resolution |
96*96 pixel H*W |
|
Cabinet Size |
1024*1024mm H*W |
|
Physical density |
9216 pixels/cabinet |
|
Module quantity |
16pcs=4(H)*4(W) |
|
Material |
steel |
|
Weight |
57KGs |
Electricity
parameter |
Brightness |
9000 nits |
|
Brightness adjusted |
100 grade by software or by Auto-optic induced |
|
Color processing |
8 bits (256) |
|
Display color |
16 millions |
|
Color temperature(k) |
7,200k |
|
Physical density |
8800 pixels/per square meter |
|
Whole display flatness |
≤ 1mm |
|
Best view distance |
6 - 45m |
|
View angle |
V≥50° H≥110° |
|
Storage temperature |
40 degree -60 degree |
|
Working temperature |
2 degree - 60 degree |
|
Driving Method |
Constant driving current Scan: 1/4 |
|
Refresh frequency |
up to 3000Hz |
|
Frame rate |
25 - 75Hz |
|
Humidity(RH) |
10% - 90% |
|
Protection grade |
Front IP65, Rear IP54 if not specified |
|
Working voltage |
DC 5V |
|
Power supply |
AC 110V ±10% / 220V ±10% |
|
Average power consumption |
220w/per square meter |
|
Max power consumption |
660w/per square meter |
|
MTBF |
10,000 hours |
|
Screen lifetime |
100,000 hours |
Control
System |
Control System |
Linsn |
|
Signal Interface |
DVI |
|
Communication distance |
CAT5cable:≤100m Fiber Cable:≥500m |
|
Signal transfer mode |
dot to dot synchronized with computer monitor |
