Advantage:
1. 5pcs 30W RGB 3in1 COB LEDs, High brightness, Uniform spot
2. Each LED Can be controlled individually
3. Unit lamp can be connected, like display, or other shapes
Technology Parameter:
Voltage: AC100-240V , 50/60Hz
Power: 150W
Light source: 5pcs 30w COB RGB 3in1 LEDs
DMX 8/20 channels selectable
Each LED can be controlled individually
Sound controlled via built-in microphone
Adjustable sound sensitivity
Function: Color mix, automatic color change, built-in program and strobe effect with adjustable speed, dimmer, master/slave
LED display, easy to control
Full DMX512 control
Unit can be connected and program differently.
With Safety loop
Package size: 62X15X16CM
Weight: 3.5kg
DMX Channel:
DMX CH | Function | remark |
CH1 | Dimmer | WDimming,linear dimmingfromdark to bright |
CH2 | Strobe | W Strobe,Speed,from slow to fast |
CH3 | Function | 0--20:DMX 7CH;21--70:Color Jump;71--120:Color Fade;121--170:Colorpulse;171--220:Running;221--240:Sound control 1;241--255:Sound control 2 |
CH4 | Speed | Speed Function from slow to fast |
CH5 | R Dimming | R Dimming, linear dimming from dark to bright |
CH6 | G dimming | G Dimming, linear dimming from dark to bright |
CH7 | B dimming | B Dimming, linear dimming from dark to bright |
CH8 | DMX512 ID | ID 1 5--9 ID 2 10--14 ID 3 15--19 ID 4 20--24 ........ ......... ID 51 255 under sameaddress code, single-control lighting up to 50 Maximum |
