This product adopts high brightness LED as the light source with low pressure constant current drive. It is safe&reliable, less electricity consumption and long lifespan. The frame processing from pure aluminium is made through anodic oxidation. Its appearance is concise&vogue, never unfading, good thermal management can effectively ensure LED's working with the long-term stability. It has used high pervious acrylic. It can shine homogeneous & soft light and have high light output efficiency. The whole lamp is simply operated. It can be lighted up instantly, no flash, no stridor, no glare, no lead, no mercury, etc. Harmful substance. The lamps is easy to installation and can be hang on the wall to replace the ceiling or grille lights with the same specifications. It is widely used in the conference room, top-grade office and other places. We also can hoist it through the erection opening on the back of light body.
Features:
1 Leading power supply design and overlong lifespan.
2 There is no mercury&lead, etc. Harmful substance which is bad for environment.
3 It is energy saving, environmental protection and high brightness. And it can save 65% electricity compared with traditional grid lamp.
4 It can work instantly without flash, stridor and glare.
5 It won't be obstructed by wireless.
6 It is without infrared, ultraviolet and no heating effect.
7 It is ultra-thin & ultra light with fine circuit design. Single dead LED won't affect overall lighting effect and lifespan.
8 Side lighting is homogeneous & soft and comfortable&bright. It can alleviate eyes' fatigue
With wider lighting angle.
9 Its appearance is concise&vogue, pretty&elegant and never unfading.
10 Fast&convenient installation. It can be hang on the wall to replace the ceiling or grille lights
With the same specification. Or it can be hanged on the roof through the chain.
11 The constant-current drive can guarantee the normal operation of panel lamp during
Unstable voltage.
Monochrome technology parameters:
Items
Symbol
Volume
Unit
Working current
I
900
MA
Power
P
20
W
LED(3014)quantity
PCS
308
PCS
Lumen
Lm
3216.8
Lm
Color temperature
K
3000
K
Dimensions
L*W*H
600*600*12.0
Mm
Working temperature
TOPR
-25---60
Dg
Storage temperature
TOPR
-40---80
Dg
Voltage
VOLT
AC85-265V
V
Grade of waterproof
IP
IP54
IP
Circuit board
Material
Aluminium PCB
/
Lifespan
HOUR
50000
HOUR
Power factor
PF
0.95
/
Power efficiency
Η
0.85
/
Lumen Decrease:
Operating Time (hour)
Lumen Decrease%
1000
4
3000
10
5000
15
Product size picture:
Unit: MM
Illumination and Distribution curve flux:
Packing Size:
Item
Unit Size
Uint Weight
Packing QTY
Carton Size
Carton Weight
RM-07-PL-20W-6*6/3014 LED panel light
660*630*55MM
5.8Kg
5PCS
680*300*650MM
Kg
The input voltage is AC86-AC265V, if needed, extend the power input terminal wiring to access the utility electricity, when installing, please cut off electricity to avoid the electric shock. This product is waterproofed IP54 for indoor use. Please don't use it in high-temperature places. When the temperature is much too high, the thermal control circuit will automatically work, and the output will be cut off, the light will then be off for a few minutes, it will get back to normal when the temperature is lowered.
Warranty: One month for guarantee replaceThe lights on a shifting, 2 year warranty.
Note: After opening package, please examine carefully and see if there is any damage or injury. If there is any problem resulting from the transport, please notify the supplier immediately, do not use damaged lights by yourself.
