E14W2WCW-FP
FEATURES:
1.The bulb shape is simple and elegant, 360 ° Beam Angle and has a LED light bulb
high brightness, long life, low energy consumption, environmental protection and
other advantages.
2. Using RC Buck drive power, stable performance.
3. 20,000 hours rated average life.
4. Sophisticated, refined appearance.
5. Instant start, no flicker, no iris, no dark areas.
6. Free of halogen, mercury and other harmful substances, RoHS compliant.
PURPOSE:
Provide solid-state lighting of energy saving.
APPLICATION:
Mainly used in homes, shopping malls, hotels, meeting rooms, exhibition halls
and other indoor places lighting instead of incandescent lamp.
Environmental Condition:
ItemConditionNotes
Operation Temperature [°C ]
-35 ~ +50
Storage Temperature [°C ]
-35 ~ +60
Light intensity distribution:
Illumination at a distance:
Installing and Using:
1. This product is E14 screw type,Clockwise screwed into the holder and then
turn 85V-265Vac power supply.
Note :( This light easy to use, regardless of the zero line and the line of fire,
as long as 85V-265Vac voltage value, any connection)
Warning:
1. Please use the correct power supply voltage to the LED bulb powered
misconnection voltage may cause permanent damage to the fixture.
2. When the installation and replacement of this product, you must cut off the power.
3. Before unpacking, please verified bulb there exist damage caused during transport.
If there is damage, Please stop using it immediately.
4. Bulb should be used away from the heat source , Maintain ventilation fixtures
working environment, to ensure that their work environment suitable temperature.
5. Do not use wet or rain shower in the long term to the place.
6.This product is not suitable for dimming.
