1.Parameters
| Model No. | Lamps | Clip Q'ty
(PCS) | Product Size
L*W*H(mm) | LF(mm) | Q'tu/CTN
(PCS) | Carton Size
(mm) |
| YH4118T | 1*18W T8 G13 | 4 | 660*88*95 | 400 | 12 | 690*280*270 |
| YH4218T | 2*18W T8 G13 | 6 | 660*135*95 | 400 | 9 | 690*425*210 |
| YH4136T | 1*36W T8 G13 | 8 | 1270*88*95 | 900 | 9 | 1290*280*210 |
| YH4236T | 2*36W T8 G13 | 8 | 1270*135*95 | 900 | 6 | 1290*280*210 |
| YH4158T | 1*56W T8 G13 | 10 | 1570*88*95 | 1000 | 9 | 1595*280*210 |
| YH4258T | 2*56W T8 G13 | 10 | 1570*135*95 | 1000 | 6 | 1595*280*210 |
2.Product description:
1.Natural silicon gel gasket used in the housing.
2.PC clips or S/S clips for locking and waterproof cable gland on side of the housing to ensure good waterproof function.
3.Many types combinations between housing (ABS,PC)and diffuser(PS,PMMA,PC)to meet different requests.
4.PC wire clips to ensure electrical safety.
5.Prismatic diffuser with unique shape design to get average ray,efficient usage of light and good dazzle-proof effect.
6.Easy and quickto installation under ceiling or on surface.
7.Plastic gear tray holder connected to the housing for easy maintenance.
Housing : Injection mouled ,high mechanical resistant ,self-excitinguidhing , RAL7035 light grey polycarbonate ;( ABS for option)
Diffuser : Injection moulded ,V0 self-extinguishing ,UV stabilised transparent polycarbonate , prismatic inside for better light control;
Reflector : high quality iron sheet with white power coating
Lampholder : T8-G13, Polycarbonate and High quality copper matrial ; tube rotation protection ; VDE and ENEC certifiled ;
Ballast : EE1 = B2 magnetic ballat or EE1 =A2 electrronic ballast (PHILIPS , OSRAM , TRIDONIC brand)
Terminal block : 3poles screw type ,or 3poles screwless type ; (5poles for option)
Clip: Polycarbonate clips or Stainless clips for option ;
Mounting bracket : Stainless bracketets ;
Installation : Easy and quick to install under celling or on surface .
Hanger : Plastic gear tray holder connected to te gousing for easy maintenace .
Accessory bag : Ruber gomment , PG13.5 cable gland , expansion pipe and screws .
Applications : Approved for indoo use or outdoor use which nedd waterproof ,dustproof and moistureproof
Friendly reminder : 1) must not be installed on surfaces subject to strong vibrations : must not be installed
2)when using PC difuser ,don't use moderately to trong alkaline or acidic material or solvents or cleaning agents which attack PC material
3)special enviroment using , pls contact us
