The feature
Super power dot-matrix white LED with strong light effect, long service life and low light decline feature.
The housing adopts high thermal conductivity aluminum to enhance heat dispersion property.
Twice direct cooling heat sink processing enable to increase the cooling coefficient and prolong the service life of the product.
Normal on. Photosensitive sensor is optional.
IP66 waterproof and dustproof housing available work at ambient temperature -40 degree celsius to 50 degree celsius.
BASIC FUNCTION
Reduce the equipment cost
Lower cost of installing and wiring
1.Specification
LED quantity 12pcs 3W high power LED
Color temperature 3000-3500K(warm white)/5500-6000K(cool white)
Luminous flux 2400lm
Input voltage AC110-220V, DC12V/AC24V can be customized
Frequency 50-60Hz
Plug type Country standard
Power consumption 26W
Day/night switch Auto
Bracket "U" bracket
Ambient temperature -40 degree celsius to 50 degree celsius
Protection grade IP66
Color Beige
Shell material Aluminum die casting + Tempered glass panel
Net weight 1.25KG
Gross weight 2KG
Product size 135*110*91(mm)
Packing dimension 200*180*140(mm)
Additional function Photosensor is optional, which can achieve day-night auto swith function.
Installation:
Heavy-duty stainless steel bracket provides flexible mounting solutions for postop, wall or ceiling mount with various light angles adjustable.
Application:
Scene LED Floodlights are are widely used in facade of building, billboards, Metro,tunnel, highway, countryroad, mountainous road, residential community, public garden, parking lots, exhibition room , etc.
2. I. Dimension, II. View angle & III. Material & Packing
