1.Technical Parameters:
| Item# | Power | Lumen | LED Q'ty | IP Rate | Product Size(mm) | LF(mm) | Carton Size(mm) |
| EBH-7W-W | 7W | 550 | 48 | IP66 | 290x200x95 | w178 | 410*420*315 |
| EBH-7W-H | 7W | 550 | 48 | 290x200x95 | L268 | 410*420*315 |
2.Technical Features:
1.Input Voltage: 100-277V
2.Frequency: 50/60Hz
3.IP Rate: IP66
4.Driver : constant current LED driver
5.Lumen:550lm
6.LED Source: SMD2835
7.LED Chip: Lextar, Epistar, SAMSUNG
8.CCT: 3000K 4000K 5000K 6500K
9.Ra: >80
10.Luminous Efficiency: >85lm / W
11.Working Temperature: -20 ºC to +40 ºC
12.Warranty: 5 Years
3.Description:
1.Polycarbonate injection mould housing, with silicon gasket to guarantee IP65 protection.
2.Opal polycarbonate diffuser with UV protection, high impact resistant IK10.
3.Rapid connection system.
4.Easy installation with 304 stainless fixation to the ceiling.
4.Product Options:
1.Emergency pack
2.Microwave senser
3.Dimmable driver
| Model No. | Total power | LED Q'ty | IP Rating | Difuser Type | Lumen |
| SBH-14W | 14W | 96PCS | IP66 | Opal | 1100 |
| RBH-14W-W | 14W | 96PCS | 1100 |
| RBH-7W-H | 7W | 48PCS | 520 |
| Color Temperature | Product Size LxWxH(mm0 | LF (mm) | Q'ty/CTN(PCS) | Carton Size (mm) |
| 3000K,4000K,6500K | 288x288x88 | φ268 | 8 | 595x35x315 |
| φ301x95 | φ281 | 8 | 625x410x325 |
| φ301x95 | φ281 | 8 | 625x410x325 |
Production description
Input Voltage : AV220-240V or AV100-277V,60/60Hz
IP rATING : IP66,Class : I I
Driver : CONSTANT current LED driver .
Housing ; Polycartbonate material , high impact resistant , IK10 .
GWT 850 degrees ,white or black color for your option .
Diffuser : Polycarbonate material , high impacy resistsnt ,IK10.
GWT 850 degrees ,UV protetion.
High temperature resistant PCB for SMD LED
Natural silicon gel gasket ,ensure waterproof dustproof
With cable gland for the good waterproof function .
Quick wiring system ,save installation time ,save money
Easy and quick installation under celling or wall-mounted
Warranty : 3 years
It could be fitted with sensor and emergency function
Suitble for corridor ,undergound parking ,warehouse,etc
