Indoor Video Full Color P4 Curtain LED Display
1. CE. RoHS. FCC. C-Tick authorized;
2. ISO9001: 2008 QC system;
3. 100.000 hours life span;
4. AC 90V to 240V power input;
5. Video. Flash. Animation. Graphic. Text available;
6. PC controlled in real time;
7. Installation structure drawing offered FOC;
8. Easy for installation;
9. 2 years warranty offered;
10. 1% spare parts offered FOC;
11. Training in our factory offered FOC;
12. On-line remote service is available;
13. EXW. FOB. CIF accepted;
14. Factory visiting and inspecting is welcome;
15. OEM service offered;
16. Models available:
P4mm. P5mm. P6mm. P7.625mm. P8mm. P10mm. P12mm. etc. For indoor use;
P10mm. P12mm. P16mm. P20mm. P25mm. P31.25mm. etc. For outdoor use;
LED Specification |
1 | LED Chip Brand | Red: Opto / Epistar Green & Yellow: Silan |
2 | Wave Length (nm) | R: 625nm; G: 525nm; B: 470nm |
3 | Pixel Configuration | SMD 3 in 1 |
Module & Cabinet Specification |
4 | Physics Distance Between Pixels | 4 mm |
5 | Physics Pixel Density | 62, 500Pixel/m² |
6 | Module Dimensions (W x H) | 128mmX 128mm |
7 | Physics Pixel / Module | 32 x 32 = 1024 |
8 | Cabinet Dimensions ( W x H xT) | 640mm X 640mm X 160mm |
9 | Physics Pixel / Cabinet | 160 x 160 = 25, 600 |
10 | Cabinet Weight | 20 kg |
11 | Cabinet Material | Steel Cabinet / Aluminum Cabinet |
12 | Cabinet Frame | Standard Frame Simple Frame (without backdoor) Lifting Frame (specially for rental use) |
Screen Specification |
13 | Brightness | 2500cd/m² |
14 | Viewing Distance (min, max) | 2 - 300m |
15 | Power Consumption / Screen | MAX : 1200 w/m² ; Average: 300 w/m² ; |
16 | Drive Mode | 1/16 scan, constant current driving |
17 | Refresh Rate | 600 HZ |
18 | Frame Rate | 60HZ |
19 | Display Flatness | 0.5mm |
20 | Maintenance | Back maintenance, replace the module |
21 | Led Life Span | 100, 000 hours |
22 | Supply Voltage | AC220V/50HZ, ± 10%; AC110V/60HZ, ± 10% |
23 | Operating Temperature | -20º C~+50º C |
24 | Operating Humidity | 10%-90% |
25 | Storage Temperature | -40º C~+60º C |
26 | Viewing Angle | Horizontal: 120° ; Vertical: 65° |
27 | Grey Scale | Red, green, blue each 16k |
28 | Display Colors | 4096 Billion |
29 | IP Rating | IP20 no water proof, no dust proof |
30 | Aging Time in Factory | More than 72 hours constantly |
Control |
31 | The Software | LED Studio |
32 | System Supported | Win 98 / 2000 / 2003 / XP / WIN7 |
33 | Control Mode | Real Time Control (Synchronous) |
34 | Display Capability | Flash, Video, Graphic, Text |
35 | Signal Supported | RGB, VGA, DVI, etc. |
About Advantages
1.Experienced & Professional
10 years manufacturing experience on LED displays,professional workmanship design.
2.Strict Quality Control
Careful inspection to ensure our quality before packing.
3.Competitive Price
We have the best competitive price and the same even better quality at the market.
4.Quality Guaranteeing
We control the whole process from design to produce and all our products have CE,FCC,ROHS,C-TICK certificates.
About Service
Pre-sales support
1. We offered technical advice to our customers before buying our products.
2. Help customers to choose suitable products within budget with most economy benefit.
3. Design the framework structure to install our led products with technical drawing.
4. We offered software customization for our customer's specific usage.
After- sales service
1. We promise our customers more than just two years warranty service! We provide free maintenance services including remote configuration, technical consultation, and trouble
shooting for our customer.
2. We promise a life time followup service for all the equipment supply by our company. These include continuously improve of system functions and upgrade of system software.
3. We offered training to our customer who includes operating and maintenance of our
products.
Shenzhen Comcreating Co., Ltd is a professional enterprise engaged in the LED display system research, productionn, sale and service. Our main products include outdoor / indoor LED Display. More than 200 employees work in our company. 50 sets of advanced equipments including lastest automatic optic-electronic test system are furnished in product line. The output is more than 1000 sq. M/month.
Due to our highly skilled R&D staff and the newest technology, all of our products enjoying world-wide reputation for their precise quality, competitive price and the best service guarantee. OEMs/ODMs are welcomed.
Comcreating has provided more than 3000 LED display for over 86 countries and districts. We have builded a mutually beneficail relationship with our customers. In the coming days, we will be more strictly urge our team to offer you LED display with excellent quality, competitive price and better service. Wish we can work together with you to create a win-win relationship!
