Product Description:
(1)Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
(2) 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade.
(3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
(4) Line-Double technology is adopted for the picture adjustment.
(5) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.
(6) Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof.
|
Specification |
PH3 SMD |
|
LED Lights |
3 in 1 |
|
Pixel Pitch |
3mm |
|
Pixel Resolution |
111111 dots |
|
Pixel Composing |
1R1G1B |
|
Module Dimension(W*H) |
240mm*135mm |
|
Module Graphic Definition |
80*45 |
|
Cabinet Dimension(W*H) |
480*540*45mm |
|
Cabinet Graphic Definition |
160*180 |
|
Single Cabinet Weight |
35kg |
|
Best Viewing Angle |
>3m |
|
Horizontal Viewing Angle |
120° |
|
Vertical Viewing Angle |
100°~120° |
|
Average Power Consumption |
600W |
|
Maximum Power Consumption |
≤1200W |
|
Graphic Card |
DVI |
|
Control Method |
synchronization |
|
LED Driver |
constant current |
|
Scan Mode |
1/16 scan |
|
Frame Changing Frequence |
≥60Hz |
|
Refresh Rates |
≥2000Hz |
|
Brightness |
≥3500cd |
|
Ingress protection(Front/Rear) |
IP54/IP40 |
|
Operation Temperature |
-20°C~50°C |
|
Operation Humidity |
10%~95% |
|
Inpur Voltage |
AC220V/110V±15% 47-64Hz |
|
Gray Scale |
4096 |
|
Brightness Adjustment |
256 level |
|
System Operating Platform |
WINXP,WIN2000,WIN98 etc |
|
Support Mode |
DVI,VGA,S-Video,RGBHV,COMPOSITION etc |
|
Control System |
DVI graphic card+control card(gigabyte)+optical fibre transmission(option) |
|
NTBF |
≥10000 hours |
SHENZHEN KINGDIGITALS ELECTRONICS Co., Ltd. is one of the professional LED Products manufacturer in China. Our Main products is Indoor full color LED display, Outdoor LED display, Single/double color LED signs, Rental LED display and LED lighting. The main products of our company have been exported to North America, Europe, Southeast Asia and other regions.
For the past few years, we commit to promote our brand. On the same time, OEM and ODM business are also accepted. We understand the delicate balance between R&D, manufacturing and marketing both domestically and abroad.
Under the philosophy of "Quality First, Credit Top and Customer Uppermost", we keep improving in management and have gained unanimous recognition from domestic and foreign customers on quality, delivery and service.
Join us, we make more better tomorrow.
