Features:
Lightweight
Easy assemble
High contrast and Precision
No fans design
Available pixel pitch: 3mm, 4mm, 5mm, 6mm
Description:
High-Contrast
SMD black light, wider viewing angle, high-contrast(4000:1)
Fast Lock Design
Special design for rental application with fast locks and simple tool setting-up method, the display can be installed quickly to save time.
Slim and Light:
Cabinet weight is only 8.5 kg, thickness is 85 mm, decreasing the transportation cost and the intensity of labor
Applications:
Indoor stage, TV studio, concert, Theme park, airport, station, Exhibition where need quick installation
Specifications:
| Model Number | GLIR500-4 |
| Pixel Pitch | 4.81mm |
| Pixel Density/ | 43,264dots |
| LED Configuration | 1R1G1B SMD2121 |
| Module Size | 250mm×250 mm |
| Module Resolution | 52dots×52dots |
| Panel Dimension (W×H×D | 500×500×84mm (19.7''*19.7''*3.3'') |
| Panel Resolution | 104dots×104dots |
| Minimum Viewing Distance | 5m |
| Panel Weight | 8.5KG (18.7 lbs) |
| Refresh Rate | ≥ 1000 Hz |
| Brightness | ≥1800cd/ m2 |
| Power Consumption | Avg:100W/Panel Max:200 W/Panel |
| Viewing Angle(H/V) | 140°/140° |
| Lifespan | 100,000 hours at 50% brightness |
| Operating Temperature | -20ºC~ +45ºC |
| IP Rating | IP3X |
| Certifications | CE, RoHS |
| Control System | Linsn /Nova |
We specialize in this field for several years with good quality and pretty competitive price.
Our products cover indoor, outdoor, curtain and curved LED display which can be applied in many situations for different purposes.
