Parameters
Pixel
Pixel pitch: pH4.8
Pixel configeration: 1R1G1B
ChipWaveBrightness
REpistar620-625nm300mcd
Packaging: SMD3528GSilan520+/_1.25nm850mcd
B 470+/_1.25nm180mcd
Module Size: 240mm*240mm
Module Resolution: 50*50
Phsycal Density: 2500 dots/module
Cabinet Size: 480mm*480mm*67mm
Cabinet Type: Rental slim aluminum cabinet
Cabinet Resolution: 100pixels*100pixels
Phsycal Density: 10000 dots/cabinet
Module Qtd: 4 PCS=2(h)*2(w)
Weight: 7kg/PC
Electricity Parameters
Brightness: ≥ 1600CD/
Brightness adjusted: 256degree or auto-adjusted
Color processing: 16bits
Display color: 280 trillion
Color temperature: 5000--9500K(decided by user)
Physical density: 43403 pixels/
Whole display flatness: =<1mm juncture
Best view distance: ≥ 4.8m
Best view angle: Horizontal ± 80° ; Vertical ± 80°
Storage temperature: -35~+85 Working temperature: -20~+50
Driving mode: Constant driving current Scan: 1/15
Refresh rate: 600Hz
Frame rate: ≥ 60Hz
Humidity(RH): ≤ 90~95%
Protection grade: Indoor IP43
Working voltage: DC 5V
Power supply: AC 220V; 60Hz
Average power consumption: 200W/
Max power consumption: 400W/
MTBF: 10, 000 hours
Screen lifetime: 100, 000 hours
Signal inerface: Composite Video, S-Video, DVI, CATV
Communication distance: 100m (network cable) / 500m (multimode fiber) / 20Km (single mode fiber)
Marks
Price terms: FOB Shenzhen
Valid time: 30 days
Payment terms: T/T in advance, 40% deposit and the balance 60% will be paid before shipment.
Delivery time: 20 working days
Warranty time: 2 years
Shenzhen CLT Technology Co., Ltd., is a professional LED display high-tech company, specialized in R&D, manufacture, sales and service of LED display, provide integrated LED display solutions, our products cover various indoor and outdoor application such as rental, advertising, mobile, stadium, LED curtain, curve screen etc.
Our company developed rapidly recent years, we became the largest SMD display manufacture at the end of 2008, CLT industry park which covers 20000m2 was put into use in 2009, Own 8 modernized dustless, anti-static production lines and top class production equipments, including 6 new Panasonic high speed SMT machines and large leadless reflow oven. We¡ ¯ Ve realized full automation manufacture, highly secure reliability of the LEDs, which can satisfy our customers¡ ¯ Various requirements. CLT performs according to the standard of ISO9001: 2008. Our products passed the international Certificates as CE¡ ¢ RoHS¡ ¢ CCC¡ ¢ FCC etc, which ensure the reliability of LED display and fast delivery request.
CLT carry out the distributor management mode which share benefits and develop with customers, we provide the ODM&OEM service for LED display factories, distributors and engineering contractor. In June, 2009 we held the first distributors meeting in Shenzhen, which also was the first one in LED industry. Now we have the complete distributor network except Tibet and Taiwan in China, which provide the fast well local service for customers.
