1. Features:
(1)Is09001-2008, CE and ROHS certificates
(2)China manufacturer high quality and competive price
(3)High efficiency
(4)Industrial standard size
(5)Luminous evenly distributed on each segment
(6)Provides excellent reliability in bright ambient light
(7)Sold state reliability
(8)long life according to experiments
(9)Size and colors can be provide by your application
(10)Low power consumption
(11)Chips sourced from TaiWan and America
(12)Imported PCB
(13)Fire proof REF
(14)Fits different LED display size specifications
2. Product Description
(1) Color: Many colors are available, such as Red, Yellow, Blue, Green.
(2) Reliable material.
(3)Various digit quantity are available: 1digit 2digits 3digits 4digits 5digits 6digits and 7digits etc.
3. Parameter:
Power dissipation: 38mW
Peak forward current: 60mA
Continuous forward current: 20mA
Reverse voltage: 5V
Operating Temperature Range: -20+65° C
Static Temperature RangeT: -20+70° C
Static Voltage: 1000V
4. Absolute Maximum Ratings
Lead Sodering Temperature: 260° C for 3 seconds
For operation above 25° C, The Ifm Ifp & Pd must be derated, the Curent derating is 0.36mA/° C for DC
Drive and -0.86mA/° C for Pulse drive, the power dissipation is -0.75mW/° C. The product working current
Must not more than the 60% of the Ifm or Ifp according to the working temperature.
We always do our best!
Contacts us!
Have a good mood everyday! *^_^*
type |
Digit size |
Dimensions(L*W*H) |
Color |
polanity |
Three
Digit
Led
display |
0.25inch |
10*8*4mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.36inch |
22.5*14*7.2mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.39inch |
20.1*16*7/30.02*12.8*7mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.4inch |
30.1*16*7mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.48inch |
24.9*18.9*8mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.5inch |
25*19*8mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.52inch |
37.8*17.5*7mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.56inch |
37.6*19*8/29.8*23.5*8mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
0.8inch |
59.3*27.5*84/53.9*25.8*8.5mm |
Red/green/blue/yellow/amble/white |
Common cathode/anode |
After over 8 years' construction and development since found in 2006, Aite Aiko Technology (shenzhen) Limited has become a professional manufacturer, specialized in R&D, manufacturing and marketing. In order to increase the product value, the company introduce advanced Automatic equipment, employ and train high-qualified talents in management & technique. Under management system of ISO9001-2008 and ISO14001, the product quality and production efficiency are highly improved.
With the far-sighted R & D and innovation capacity, the company has had multiple product series, mainly digital displays, displays for household appliances, displays for multimedia, DOT matrix displays and other customized displays etc, which enable us to satisfy all kinds of customers. Up to now, the company has gained trust of customers in Pearl River Delta area, and famous brand company like Gree, Media, Hisence, Topband to be partner.
In order to gain the potential market, the company is strictly applying the industrial and international standards to ensure the product quality. All the products meet RoHS and Reach requirements, and 2 years' warranty is applied. To strengthen enterprise cohesive force, the company enhance the humanistic concern, and develop training & performance assessment system to encourage employees to show their talents.
Aite Aiko aimed to make high-quality, the most competitive and fashionable products, to offer professional and high efficient service as well as creating higher profits for customers.
"technology first, quality the life, service the essence", the company willing to move forward with customers and sincerely welcome friends to cooperate together to create brilliant future.
