Video Link of Galaxias P4 flexible LED Curtain
| Installation video | http://youtu.be/0y4LmJh6YU4 |
| Galaxias P4 video 1 | https://youtu.be/KHGqiCmbOWI |
| Galaxias P4 Video 2 | http://youtu.be/uhXK_-KSTWM |
1. Features
1)Foldable. The LED Display is flexible and Folable, can match any shape and size of your requirement. The LED
Display widely used for preparation of various 2D and 3D shapes such as round, triangle, cylinder, and cone, etc
2)Light. The LED Display is smart and light. Saving space and the transportation cost.
2. Installation & Maintaince
1) The LED Display is easy to Install and maintaince. No tools. Just your hand.
2) Finishing installation and debugging of 5 square meters takes just 1 hour, labor cost saving a lot.;
3. Quality
High quality with the high refresh rate. All the refresh rate of Pitch size 6mm, 7.8mm, 9.3mm, 12mm, 16mm are 10, 000Hz
4. Material
The manufacturing material is DFR which makes the displays inflammable, scratch proof, heavy duty, safe, and reliable
5. Application (indoor & outdoor)
1), The curtain IP is 54, Water-proof, fire-proof Certificate.
2), The curtain is good for indoor and temporary outdoor for a few days.
6, Factor for Quotation
1), the pitch size you need or project information
2), the height and wide of LED curtain or stage
3), Shipping address in detail.
7. Warranty:
1), One year warranty
2), Free spare parts come with each order
3), Free train at factory
4), 24 hours technical support
8. Specifications
Model No.: Galaxias P4
Display Function: Vedio
Pixel: P4.6mm
Visual Distance: 4m
Density: 45512 DOT /sq. M
Refresh Rate: ≥ 10, 000 Hz
Brightness(white): 2800 nit
Display Mode: 1280*1024
Average Power Consumption: 95W/sq. M
Max Power Consumption: 280W/sq. M
Recommendation moudel size: W=600mm L=2400mm T=25mm
Weight: 11.5/sqm
Working Voltage: DC24V
Brightness Level: 16 Levels
Bit depth per color: 16 bit
Bit depth per pixel: 48 bit
Visual angel: Horizontal: 120; Vertical: 120
Drive Mode: Constant Current
Signal Type: AV, S-Vedio, VGA, CVBS, HDMI, DVI
Operating System: Windows2000/XP/Vista/Windows7
Control Distance: HSYV; Within 100m
Face Material: DFR Velvet Drapery
Ingress Protection: Front IP65. Rear: IP54
Working Temperature: -20 ~ +50
Relative Humidity: 10% - 90%
Installation: Hang
Power System: Power-600, Power-1200, Power-2000
