1, High resolution
2, Lower power consumption
3, Mult-function
4, high quality
1). Price: We have the best competitive High Cost-effective of Price/ features.
2), Automatic: From selecting LED chip, led encapsulation, PCB soldering, LED module,
Are operated by Automatic machine, improve showing effect of led screen.
3). Quality: From material to product finished, from design to produce, all steps are controlled
By our workshop, that's the guarantee of the reliability.
4). Service: All the life time 11 years is serviced free,
Warranty is up to 6 years, Service time is 24hours x 7 days,
5), Payment: Accept: T/T, L/C, D/P, D/A, MoneyGram, werstern union, and Cash.
* Products list and application area:
A: Outdoor full color LED display: Equally or compactly make the red, green, blue color in one dot,
Equally distribute at the panel, so make the whole led panel, led module, led display.
B: . Apply for physical sports, advertisement, bank, stock exchange, station, port, supermarket,
Telecommunication, school, monitor, restaurant, entertainment, etc.
C: Models P8, P10, P12, P12.5, P16, P20, P25., P31.25mm, led display, led module, LED panel
Outdoor full color P10
1, brightness DIP > 8, 000 Nits, SMD LED > 5, 000 Nits are used for outdoor led display,
Keep the content visible, even if facing the strong sunshine directly, LED panel
2, Anti-UV ray mask, the color of the mask would never change under exposure of UV ray.
3, Weatherproof design, completely outdoor use.
4, Easy for assembling and connection with the connector added.
5, High color uniformity and clear image can bring you a vivid audio visual effect.
6, Both front and rear access are available.
7, The LED Chips that we use have the advantages of large viewing angle, low power
Consumption and good color uniformity.
Since 1996, SHENZHEN BESD LED CO., LTD.
Previous name Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in
LED encapsulation and LED Display., led lamps, led lights. Owe to enlarge the company scale and build up self-owned brand, Rename
1, Fully automatic production lines
BESDLED owns the entire LED manufacturing line, encapsulate original
Semiconductor to LED chip, then assemble to led display and led lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP led,
Spectrum and Color Separation Machine,
LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and
Humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
BESDLED absorbs many talents, with more than 500 staffs, and including
More than 100 engineers and technician,
Which paves the way for R&D for new products and excellent sales service
|
Technique |
SMD |
|
Pixel structure |
1R1G1B 3in1 |
|
Pixel pitch |
4mm |
|
Pixel density |
62, 500 dots/Sq. m. |
|
Luminance |
2, 500cd/Sq. m. |
|
Module dimension |
128mm(W) * 64mm(H) |
|
Module resolution |
32 pixel(W) * 16 pixelmm(H) |
|
Cabinet dimension |
512 * 512mm |
|
Cabinet resolution |
128 * 128 |
|
Cabinet area |
0.262 sq. meter |
|
Optimal visual distance |
> 3m |
|
Visual angel |
140 degree (H/V) |
|
Max power consumption |
≤ 2600w /Sq. m. |
|
Average power consumption |
≤ 850w /Sq. m. |
|
Brightness adjustment |
Adjust according to the enviroment |
|
brightness software (0%-100%adjustable) |
|
Gray scale |
point by point 4096 gray gradelevels of |
|
each color, 16 bits γ correction avilable |
|
Drive mode |
1/8 dynamic scan, constant current |
|
Frame frequency |
≥ 60HZ |
|
Refresh frequency |
≥ 480HZ |
|
Input voltage |
AC 90~260 volts |
|
Operation temperature |
-40° C~ +60° C |
|
Operation humidity |
10%~90% |
|
Input signal |
video, s-videl, RGB digital signal etc. |
|
Inout signal |
S-video, RF, RGB, Yuv, YC, composite^ |
|
Control system |
DVI card + master control card + receiver card |
|
MTBF |
> 5000 hrs |
|
Life span (50% brightness) |
100, 000 hrs |
|
Malfunction dot rate |
1/10000 |
|
Ingress protection rate |
IP31 |
|
Cabinet material |
Epoxy paint coated, aluminum / iron |
|
Application: |
Rental / Permanent installation available |
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
After Warranty, only charge the material cost.
All the life time, Technology support is free.
