Transparent led curtain display
Stage used led curtain display video screen
Feature:
1. High-quality RGB 3-in-1 LED, high brightness.
2. Small volume and light weight, easy transportation.
3. Ventilative, transparent transparency rating reach at 70%, outdoor application.
4. Soft, can be folded up, apply to many different shapes.
5. Easy to install and convenient to maintain.
6. Many pieces can be combined together.
Specification:
Resolution: Pitch 20.83mm
Density: 2304dots/SQ. M
Pixel: RGB 3-in-1 LED
Bit depth per color: 16 bit
Bit depth per pixel: 48bit
Viewing angle: 120º × 120º
Service life: 80000 hours
Brightness (white): 3070nits
Brightness level: 16 levels
Fresh frequency: 60Hz
Innovation: ≥ 600Hz
Drive mode: Constant current
Control mode: VGA synchronous display
Display mode: 1024× 768, 1280× 1024
Display port: DVI
Working voltage: 90~264VAC 50/60Hz
MAX. Power consumed: 360W/ SQ. M
Average power consumed: 148W/ SQ. M
Face material: DFR velvet drapery
Weight: 3.8kgs/ SQ. M
Weather rating: IP 44
Transparence: 38%
Ambient relative humidity: 10%~90%
Working temperature: -10 ~50 Degree
Package: Carton (Flight case optional)
Recommendation Size: 0.8m width x 2m height
Installation: Hang
Control system: HC-101, HC-103 or HC-102
Safety certificate: CE, FCC, RoHS
Huasun Technology Co., Ltd
Huasun has very rich experiences in flexible LED display technology. The company has more than 10 relevant patents and is dedicated to making the LED display even lighter, thinner, and allowing more people to enjoy the convenience and great experience in technology innovation.
We would be very glad to offer any further assistance. Please contact us if you need any additional information. This is Angel Lee, from HUASUN TECHNOLOGY CO., LTD
Huasun Technology Co., Ltd. is a high-tech enterprise that is engaged in the researching, developing, producing, marketing, and engineer service of LED display and LED lighting. It has been grown in Beijing, capital of China, for over ten years. The main products and services include LED display system, LED digital stage system, LED lighting system. With a business principle of technological innovation and professional service, the company commits to provide high-quality LED products and solutions for all clients.
The company has a R&D team made up of senior engineers. Taking advantage of the technological and cultural resource in the Capital of China, working together with experts in mechanism, optics, and electronics from the main universities, the team is devoted to the research and application of multimedia technology and has gained the leading position in product design, software development, mechanical design and optical application. The company has own many national invention patents in LED display technology. Flexible LED display, one of our patents, is a landmark product in the development of LED display. It is widely used by the clients from all over the world for the advantages of compact size, light weight, and easy installation. We always keep in mind that the mission and responsibility of the enterprise is to change the world by pioneer spirit and innovative product in a technology high speed age. We are always proud of it.
Welcome to future of Huasun: A brighten future.
