Feature:
1. Modern light body design
2. Die-casting aluminum casing and high intensity toughened glass cover, the surface did special treatment which resisting acid, alkali and salt erosion. It has perfect appearance and excellent heat dispersion.
3. High efficiency and power factor LED driver; Wide radiation angle, huge lighting area
4. Start without delay and flicker free
5. High waterproof rate
6. The LED floodlight can save enrgy more than 50%
7. Warranty: 3years
8. Ideal heat dissipation design
9. CE RoHS certification
Applications:
1. Tunnel, Subway, Underground Lighting;
2. Gymnasium, Sports Stadium Lighting;
3. Building, Billboard Lighting;
4. Gas Station, Garage Lighting;
5. Park, Garden Lighting;
6. Workshop, Factory Lighting;
7. Warehouse, Storage Lighting;
8. Yard, Square Lighting;
9. Road, Highway Lighting;
10. Station, Dock Lighting etc
Our service:
1. Your inquiry related to our products or prices will be replied in 12 hours.
2. Experienced staffs to answer all your enquires in fluent English.
3. Clients' special requirement accepted. We can help you to design and put into product.
Warranty terms:
A), Under the terms of this warranty, if the product have a failure occurs under normal usage within warranty period, we will provide free/remake new components to replace based on the proof-documents;
B), If Failure or damage due to incorrect operation, wire connection, or anything other do not follow our instuction, we will provide paid maintenance within warranty period
Why chose us?
A), Founded in 2003, Our factory have devoted itself in the LED lighting fixture developing and designing. Rich experienced in products manufacturing.
B), Due to our years of ODM/OEM experience in project lighting fixtures developing and self-ability, We can provide high cost performance LED project lighting products for our dear customers.
C), Our mainly products in Smart LED project light, Can also provide customize services according to your requests to develop your suitable smart LED lighting fixtures.
D), We are manufacture self-producing, self-marketing, We can help customer solve any kinds of technology problems and devoted ourself to provide more professional and efficient service to all our customers
Model NO.
|
LED CHIP quantity
|
LED Current
|
In put Volt
|
Output Volt
|
Out Current
|
LED S/P
|
PF
|
JH-TG10W
|
10PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
300MA
|
10S/1P
|
≥0.9
|
JH-TG20W
|
20PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
600MA
|
10S/2P
|
≥0.9
|
JH-TG30W
|
30PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
900MA
|
10S/3P
|
≥0.9
|
JH-TG50W
|
50PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
1500MA
|
10S/5P
|
≥0.9
|
JH-TG70W
|
70PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
2100MA
|
10S/7P
|
≥0.9
|
JH-TG100W
|
100PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
3000MA
|
10S/10P
|
≥0.9
|
JH-TG120W
|
120PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
3600MA
|
10S/12P
|
≥0.9
|
JH-TG150W
|
150PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
4500MA
|
10S/15P
|
≥0.9
|
JH-TG200W
|
200PCS
|
300-320MA
|
AC100-240V
|
DC31-36V
|
6000MA
|
10S/20P
|
≥0.9
|
LED Chipset Brand: Taiwan chips
|
LED Luminous Efficiency: 10 0LM±5%
|
LED Chipset Size 3 5* 3 5MIL
|
Lamp Luminous Efficiency: 90 LM/W ±5%
|
Color Temperature(CCT):3000K-6500K
|
Lampshade Material:Aluminium heat dissipation + Toughened glass
|
Color Rendering Index(CRI): ≥ 70
|
IP Rating:IP65 Frequency Range:50/60Hz CE RoHS
|
Shenzhen Jiahong Guangyuan Technology Development Co., Ltd established in 2003, is a leading manufacturer of LED industrial lights with mainly products including: LED Tri-proof light, LED flood light, LED plant growing light, LED Tunnel light, LED high bay light, LED flood light, LED street lamp, LED gas station light, LED ceiling light and so on.
Based on the developing of industrial lighting fixture, we devoted ourself to the exploitation and application of the Smart LED products and to be the professional supplier for the environmental friendly smart LED systems as well as the LED lightings.
Customized products also available here. So welcome you send your creative design and reqirements to us and we will try our best to make your idea come true.
With the hard and efficient working of our developing team, Our innovative functional new products come out constantly. Welcome you contact us anytime. And wish we all will have a fruitful and mutual successful business cooperation in the very near future and from hereafter.
