High Brightness P10 SMD Indoor LED Display
| Price: |
US $ 1166/Square Meter |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Square Meter |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
P10mm SMD full-colour Indoor LED display
Can use structure installation
Specification
1, LED lamp Quantity: 1R1G1B SMD 3 in 1
2, Brightness: >1600(CD/m2)
3, Pixel Pitch: 10 mm
4, Pixel Density: 10000 dts/
5, Viewing Angle: Horizontal: 160; Vertical: 160
6, Maximum Power Consumption: 700 W/
7, Operating Temperature: -25--+45
8, Display Method: True
9, LED Drive Method: Constant Current
10, Viewing distance: >5m
This kind of display can be used in indoor sites such exhibition hall, hotel, small stadium, cafe and so on.
number |
Item name |
Parameter and index |
unit module |
| 1 |
Pixel composition |
1R1G1B (SMD3528) |
| 2 |
Pixel pitch |
10mm |
| 3 |
Horizontal axis |
160° |
| 4 |
Vertical axis |
160° |
| 5 |
Scan method |
1/4 |
| 6 |
Module resolution |
16× 16 pixels |
| 7 |
Module dimensions |
160mm× 160mm |
unit cabinet |
| 1 |
Cabinet resolution |
64× 64 pixels |
| 2 |
Cabinet dimension |
640mm× 640mm |
| 3 |
Cabinet depth |
110mm |
Entire screen |
| 1 |
Brightness |
> 1600 (cd/m² ) |
| 2 |
Average power consumption |
159 (W/m² ) |
| 3 |
Maximum power consumption |
635 (W/m² ) |
| 4 |
Refresh rate |
1200 Hz |
| 5 |
Viewing distance |
10-100m |
| 6 |
Brightness adjustment |
100 manual levels /100 auto levels |
7 |
Data transfer method |
Network, optical fiber |
| 8 |
Lifetime |
100, 000 hours |
| Prod Model: |
SM-P10 Indoor series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
CE/FCC; CCC; UL; RoHS |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
10mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
27,777 dots / m² |
| Scanning Mode: |
1/8 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Meeting Room,Hotel, Church |
| IP Rating: |
IP43 |
| Certification: |
Saso |
