High Brightness New LED Panel Light

18W SMD2835 Square LED Panel Light
Production introdution
New style embedded panel light,special design to prevent light leak. Make of supperior aluminum, perfect heat dissipation.

Product features:

Using high lumen SMD light source high intensity aluminum shell,fast heating.
Using good reflectivity super thin, super bright LGP which make the lights more equally.
Low voltage and constant current driver, no glare the light is soft.
Launch in 0.01sec, no flashing, no noise, no radiation. Energy saving,and environmental.
This product can show high brightness, without seeing the lamp itself.
Product accessories:
A.outer ring :GB 12#environmental-friendly aluminum is adopted and is overall die-caSt to take shape, with beautiful structural design.
B. diffuser plate:ps material from Japan Mitsubishi is used. The 1.5mm ultrathin diffuser pate has a light transmittance of up to 92%,and gentle light diffusion can effectively reduce fatigue and create the light environment.
C. Light guider:using Mitsubishi material, thickness 4mm with high precision laser dot, make the light even and comfortable, no dark space, can effectively protect the eyes.
D. reflective sheeting(round and fan-shape):the Hp LCD TV backlight reflective sheeting has superstrong light reflection,with thickness of 0.25mm-0.55mm.
E. Placed cashions:the soft polyurethane foam rubber, sealing, good elastic memory, high temperature resistant, fire retardant, effectively fixed lamp body internal optical components.
F. Rear cover:0.8mm iron back cover, dumb white,fine Elizabeth Barbara ohm two kind of spraying process,spray evenly overall sense.
G. Driver:low-voltage constant-current intelligent IC driver is used, which is of integated desing and make of the imported PC maderial,with dust prevention, compression resistance and high temperature resistance.Ambient temperature for working:-20°C-85°C

Parameter

Item NO.	Power	Size	LED Qty
PJ4021	3W	D:85     H:10    Cut:70	SMD2835*15
PJ4025	6W	D:120   H:10    Cut:106	SMD2835*30
PJ4027	9W	D:145   H: 10   Cut:130	SMD2835*45
PJ4029	12W	D:174   H: 10   Cut:156	SMD2835*60
PJ4031	15W	D:200   H: 10    Cut:182	SMD2835*75
PJ4033	18W	D:225   H: 10    Cut:201	SMD2835*90
PJ4035	24W	D:300   H: 10     Cut:274	SMD2835*120

Applications:
1. Commercial lighting
2. Office lighting
3. Warehouse lighting
4. Supermarket lighting
5. Hotels lighting
6. Homes lighting
7. Hospitals lighting
8. Classrooms lighting
9. Conference rooms lighting
10. Other indoor lighting places

Installation instructions:

This product is limited to indoor use.
Hole size of the ceiling should be the same as the lamp's cutout size.
Connect the Dcconnectors with the lamp and driver.
Insert the pinch to the ceiling, make sure it is fastened.
