High Brightness Indoor LED Display
| Price: |
US $ 200-2000/Square Meter |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Square Meter |
| Pay Type: |
L/C,T/T |
High brightness indoor led display Features:
Imported raw material from USA and Korea, Fire proof REF.
High luminance(Indoor full color >1000CD/m2 and outdoor full color >6000CD/m2),
Wavelength keep within 5nm.
Suitable for TB62726, MBI5026, MBI5027 IC driver.
Application:
It is mainly used in high-grade entertainment disco, large-scale song and dance show, fashion show, outdoor advertising signs, building curtain wall etc.
MRLED advertages
1. High brightness and brightness adjustable, able to fully meet the needs and changes of a variety of application environments.
2. Standard processing technology to ensure each row and each column lamps at the same horizontal line, and ensure light consistency and clear, stability pictures.
3. Large viewing angle, up to 110° Horizontally and 60° Vertically. Image no distortion, no color cast in any angle within this range.
4. Cabinet design lightweight, easy to maintain, IP65 high-performance waterproof and dust resistance.
|
Item |
Indoor rental led mesh screen |
|
Pixel Pitch: |
6.25mm |
7.62mm |
10.4mm |
12.5mm |
20mm |
|
Driving Method : |
1/10 |
1/8 |
1/5 |
1/4 |
1/4 |
|
LED type : |
SMD3528 |
|
Brightness: |
≥1300cd/m 2 |
≥1300cd/m 2 |
≥1300cd/m 2 |
≥1300cd/m 2 |
≥1300cd/m 2 |
|
Pixel density : |
25600pix/m 2 |
17222pix/m 2 |
9246pix/m 2 |
6400pix/m 2 |
2500pix/m 2 |
|
Viewing angle: |
120°H and 120°v |
|
Module Size(W*H): |
250*250mm |
305*366mm |
208*416mm |
200*400mm |
320*320mm |
|
Cabinet Size(W*H*D): |
500*1000*68mm |
610*732*65mm |
416*832*50mm |
400*800*50mm |
640*640*50mm |
|
Cabinet weight: |
9kg |
6kg |
6kg |
6kg |
6kg |
|
Cabinet Material: |
Aluminum sheet metal |
|
Avarage Power Consumption: |
300 W/m 2 |
28 W/m 2 |
240 W/m 2 |
210 W/m 2 |
100 W/m 2 |
|
Max Consumption : |
680 W/m 2 |
560W/m 2 |
490 W/m 2 |
430 W/m 2 |
200 W/m 2 |
|
Refresh rate: |
≥900HZ |
|
Color Depth: |
14bit |
|
voltage : |
200-240V |
|
IP Rrating: |
IP31 |
|
Operating temperature : |
-20-60 degree |
|
Storage temperature: |
-40-70 degree |
|
Operation humidity: |
10-90% |
|
Storage humidity: |
10-90% |
|
Life span (hrs): |
≥50000 |
|
MTBF (hrs) : |
≥3500 |
|
Control system: |
Linsn/Nova |
|
Source compatibility (with video processor): |
YC, VGA, DVI, YUV, SDI, RGB,CVBS,GD-SDI |
|
Compliant standard: |
CE,FCC,RoHS,ETL,CCC |
| Prod Model: |
p7.62 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP43 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Scanning Mode: |
1/4 Scan |
| Certification: |
ETL |
| Average Power Consumption: |
350W / m² |
| Pixel Pitch: |
7.62mm |
| Pixel Density: |
17222DOT/M2 |
We are the leading OEM manufactures of LED Display Screens in China, which is professionally engaged in the production of Indoor, Outdoor and Semi-Outdoor LED Display screens in Single, Bi-color and Multi color for different markets such as Malls and Plazas, Traffic guiding signs, Entertainment and Stage, Shop sign boards and huge Media Bill Boards, Security Monitors etc. We are an ISO 9001: 2000 company, CE certified, RoHS certified, export licence holders.
Shenzhen Mary Photoelectricity Co., Ltd (MRLED) is a subsidiary of state-owned listed company-- Fujian FURI Electronics Co., Ltd. And was established in 2006 April, which the registered capital is 100 Million RMB. MRLED is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays.
Experienced nine years of development, nowadays MRLED own its factory workshop area about 30, 000sqm, monthly capacity is 8000sqm, the number of employees more than 800. Company has the international first-class technology development talents and advanced production equipment, a comprehensive standardized management, product technology and quality is in the forefront between the similar products in domestic market. Also enjoy good reputation in the global market.
MR LED' products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.
In past 8 years, MRLED service team almost traveled in all over the world, always uphold the core values of "Professional, Team, Integrity, Effectiveness, Communication", provide professional, caring, attentive after-sales service for global customers. Nowadays, MRLED's products selling to over 400 cities in autonomous regions and 34 provinces in China by virtue of high reliability and cost performance, earned thousands of customers, and also had built long term business relationship with the more than 90 countries' customers, like in USA, Germany, Spain, Portugal, Thailand, Korea, Poland, Italy etc. MRLED with its reliable quality, excellent service and good faith strives for realism style, won the user's high praise from all walks of life. No matter what's the major events & Competition venues in domestic and overseas, which like in the Guangzhou Asian games, the Shanghai world expo, each big TV station in domestic, railway stations, world beach volleyball tour, and Sydney autodrome, etc. All of them have a figure of MRLED.
