Product Name:
High Power Customized Aluminum LED PCB Module with RGB
2-layered board
ENIG PCB board
Copper thickness: 1oz
Board thickness: 1.6mm
Used for LED lamps
LED PCB features:
1. Rigid & Flexible, can be made.
2. High quality products, Europoean and US standard
3.3528 or 5050 SMD LED adopted, high brightness, stable performance.
4. Long lifetime, 5% attenuation after 2500 hours, life time is 80000-100000 hours
5. Energy saving and environmental friendly.
6.5m/rell is the standard package, but the size can be customized
7. Various of LED density optional, e. G. 30LEDs/M, 60LEDs/M, 96LEDs/M. Etc.
8. Each unit of 3LEDs can be cut out at regular segments.
9.3M adhensive attached on the back of PCB, for stick installation.
10. White, warm white, red, green, blue and yellow color and RGB available.
Trade Terms:
1. Payment: T/T, (western Union or Paypal are welcome )
2. Sample lead time: 1-3days
3. Delivery time: For 100~500pcs: 1- 7days; 500~1000pcs 3-14days
4. Shipping port: Shenzhen, China
Our Service:
1. We are profession manufactory LED products in China. Offer competitive price with high quality. Maninly product LED strip, LED bulb, LED tube, LED down light, LED spotlight, LED panel light and so on
2. OEM &ODM are welcome
3. Satisfied after-sales service, welcome all requires, and we will reply it in 24 hours.
4. Unique appearance design and idel recommended services are offered
| Technical Capacity |
| Layer Counts | 1-24L | Min Board Thickness(2-layer) | 0.2mm |
| Max board size(mm) | 1200x400mm | Min Board Thickness(4-layer) | 0.4mm |
| Max copper | 12oz | Min Inner-layer Thickness | 0.1mm |
| Min Trace | 0.075mm | Min Pad Ring | 0.1mm |
| Min Clearance | 0.075mm | Min Hole Location Tolerance | ± 0.075mm |
| Min Hole Size | 0.1mm | Min Hole Size Tolerance | ± 0.05mm |
| (laser hole) |
| Board Twist | ≤ 1° | Min Outer Dimension Tolerance | ± 0.1mm |
| Base Material | FR4, High-TG FR4, CEM3, aluminum, High Frequency(Rogers, |
| Taconic, Aron, PTFE, F4B) |
| Surface Finish | HAL, lead-free HAL, ENIG, Plated Gold, Immersion Gold, OSP |
| Soldermask | Green, Blue, Black, White, Yellow, Red, Matt Green, |
| Matt Black, Matt Blue |
| Silkscreen | White, Black, Blue, Yellow |
| Acceptable File | Gerber file, Powerpcb, CAD, AUTOCAD, ORCAD, P-CAD, CAM-350, CAM2000 |
| Format |
| Certificate | ROSH, ISO9001, UL |
| Standard | 2-layer samples in about 3 days |
| Lead Time | 4-layer samples in about 5 days |
| Your inquiry will be answered within 24 hours. |
| Wishing to be your long-term partner,please feel free to contact us , we will do our best for you. |
Sograce International Corporation Limited is a professional PCB manufacturer for producing all kinds of single side, double-side and multilayer PCB, and as well as assembly service.
Established in June, 2006, our factory is located in Wanxia Industrial zone, Xinhe Road, Shajing Town, Baoan district, Shenzhen, China. We have a variety of advanced production equipment, excellent engineering and technical personnel, accompanying with the mature management and service system. Since 2006, we have successfully serviced customers in the United States, Canada, Western Europe and other regions of the world spanning many applications, business lines, and industry sectors.
Since establishment, we have been constantly improving all kinds of equipments and advanced techniques, striving to develop and produce PCB and PCBA which are used for high-tech products, such as LED, communication, network, electric power, industrial control, medical treatment, instrumentation, military projects and computer peripheral products ect.
Our products meet IEC\IPC\DIN\MIN standard, and behave ISO-9001 quality system, UL and RoHS certificate. Fast lead time and competitive price with high quality are our advantages. Production capacity is 20, 000M2 per month, the PCB lead time is within 10days, and most can be within 7days. We also established a prototype team to meet customer' S prototype needs, and the prototype lead time often can be within 3days.
With our hard work, we always satisfy the customers' High quality demand in a fast lead time under our strict management...Following the principle of "be sincere with every customer", we treat the product quality as our life. We are glad to provide you one-stop services from schematic capture and routing, PCB producing to SMT.
"High quality, Competitive price and Excellent service" is our mission which also wins the customers' Trust. Our purpose is to produce the most effective product under the advisable cost. All our consideration is built on customers' Benefit, and we benefit mutually from the business cooperation. Basing on this point, we have built a long term business relationship with lots of customers around the world, just like a blooming flowers. Warmly welcome more customers to visit and cooperate with us!
