Features:
l IP68 Waterproof
l 5 kinds of RGB control method: Remote Synchronized control, Wi-Fi Control, DMX Control,
Remote& Switch control, External control (wire control)
l Stainless steel body material+plastic embedded part+transparent PC cover
l Constant driver to make sure LED light working stably, avoid any flashing and noisy
l Voltage:AC/ DC 12V, Frequency: 50/60HZ
l High quality and brightness LED source
l Color: RGB, 14 kinds of color changing mode
Single color - white, red, green, blue, yellow
l Beam angle:SMD5050-120°
l Life span >30000 hours
l Over current protection
Main parameters:
Specification | Parameters |
Model No. | LF-P38U-9*1W |
LED Qty | 54pcs SMD5050 |
Input Voltage | 12V AC/DC |
Frequency | 50/60 Hz |
Power | 7±1w (R) 8±1w (RGB) 9±1w (G/B/W) |
Color Temperature | w.w.3000-3500K p.w.6000-7000K c.w.8000-10000K |
Luminous Flux | Blue: 110±10%Lm Red: 220±10%Lm RGB: 270±10%Lm Green: 420±10%Lm Cool White: 650±10%Lm Warm white: 680±10%Lm Pure white: 700±10%Lm |
Color Rendering Index(CRI) | Ra≥70 |
Replace halogen | 60W |
Wave length(R/G/B) | R:621-625 K/nm G:518-520 K/nm B:464-467 K/nm |
Beam angle | 120° |
Dimension | 195 x 75mm |
Working temperature | -10~+50 |
Storage Temperature | -10~+45 |
Constant driver | yes |
IP rate | IP68 |
Packing | 20 Pcs/ctn 61*41*41mm G.W.23 kg |
