Use DIP technology to make the LED display have good waterproof and anti-humidity when used.
1.Stable cabinet, stronger without distortion, anti-rust.
2.Synchronously adjust the brightness and color to make the true and exquisite image.
3.High contrast, high refresh rate make the image without any delay, trailing smear.
4.Compatible to many signal sources such as AV, S-Video, DVI, VGA, YPbPr, HDMI,SDI,DP etc.
5.Special wooden box package production protect the whole screen system.
6 .Unique waterproof cabinet design meet the standard IP65 which can be used outdoor directly.
|
Indoor or Outdoor |
Outdoor |
|
|
Pitch |
P21.33 |
|
|
Best viewing distance (meter) |
> 12 |
|
|
Pixel |
1R1G1B |
|
|
Total pixel in one square meter |
2198 |
|
|
view angle H/V (degree) |
60/120 |
|
|
Max Brightness (@ all LED white) |
9000 nits |
|
|
Scan |
static |
|
|
PCB Module Pixel (HxW) |
12x12 |
|
|
PCB Module size HxW (mm) |
256 x256 |
|
|
Max Power Module (Watt) |
40 |
|
|
PCB Module Array/ Cabinet (HxW) |
4 x 4 |
|
|
Pixel / Cabinet (HxW) |
48x48 |
|
|
Cabinet Weight (KGs) |
55 |
|
|
Cabinet Size (HxW) mm |
1024 x 1024 |
|
|
Cabinet Ingress Protection (front/rear) |
IP65/IP54 |
|
|
Max power /Cabinet (watt) |
760 |
including 20% AC-to-DC loss |
|
Data/Power Cable between cabinets from |
side |
|
|
Servicing from |
back |
|
|
Control System |
Linsn |
synchronous |
|
Editing Software |
LED Studio |
|
|
Display Content |
T+P+F+V |
T: Text, P:Picture, F:Flash, V:Video |
