Features:
Super bright SMD LED adopted, vast viewing angle and high light output
Professional, transparent lampshade applied, efficient in outputting light.
Excellent aluminum body assures ability of sinking heat, long lifetime.
Fast response, without fluorescent starter, no harm to human eye.
Long lifetime of more than 30, 000~ 50, 000 hours, ten times of the traditional, save much cost.
Around 70% energy saved under the same condition.
LED output single spectrum, soft light, no radiation to human.
Green, environment-friendly product, Lead-free and mercury-free.
Applications:
General Illumination
Commercial lighting
Cool lighting
Backlighting
Sign and Decoration Lighting
Shelf light
|
|
Symbol |
BR-T8S-60-136 |
BR-T8S-120-294 |
BR-T8S-120-336 |
BR-T8S-150-384 |
|
Dimension(Length * Dia) |
mm |
600 x26 |
1200x26 |
1200x26 |
1500x26 |
|
Total Power Consumption |
P(W) |
9W |
18w |
20W |
26w |
|
Compare traditional Tube |
P(W) |
Above 25W |
45W |
Above 50W |
Above 60W |
|
LedForward current |
IF (mA) |
240mA |
240mA |
240mA |
240mA |
|
LED Qty |
PCS |
136 |
294 |
336 |
384 |
|
Color Temperature |
TC(K) |
Warmwhite 3000K-3500K Coolwhite 6500K-7000k |
|
Led Viewing Angle |
° (Degree) |
120° |
|
Luminous Flux |
LM |
850-950lm |
1650-1750 |
1760-1860 |
2250-2350LM |
|
Illuminance |
Lux(2m) |
92-110 |
183-219 |
205-246 |
227-272 |
|
Light Efficacy |
Lm / W |
85-95Lm/w |
|
Color Index (Ra ) |
Ra |
Cool White: CRI > 75
Warm White: CRI > 83 |
|
Operating Life (Hrs) |
Hrs |
30, 000~50, 000 |
Operating environment:
|
Item |
Range |
Unit |
|
Operating Voltage |
85-165/165-265 |
AC(V) |
|
Operating Frequency |
47-62Hz |
Hz |
|
Operating Temperature |
-20~+50 |
° C |
|
Storage temperature |
-30~+45 |
° C |
Bree Lighting was founded in 2008, is a research & development, manufacturing light source in one of the professional lighting company, the company produces a new generation of compact energy saving lamps and LED lighting products. In recent years, companies have been grown in the possession of strong technical force and high-quality support of scientific research personnel, while the introduction of Japan, Taiwan and successfully developed the core technology of light out of line with next-generation stent technology standards LED T5 lamps and LED T8 fluorescent tube. This product is built-in power, small size, so that there is enough space for heat dissipation LED and lamp power cord to do without the use of internal connections, the installation more convenient, safer, longer life. A VNU's current innovative projects will lead the lighting industry, a fundamental innovation.
Bree lighting quality as the first goal, continue to study, innovation was always adhere to the belief, the company has advanced and complete testing equipment and production equipment, can be carried out strictly for each batch of prenatal and postnatal testing, which can Produced in accordance with the requirements of international standards to ensure the quality of products shipped. The company has passed, ENERGY STAR, CE, FCC, RoHS certification and many other international standards, the products are exported to Europe, America and Southeast Asia and other countries and regions, the majority of customers trust and praise!
Shenzhen Bree Lighting is a company, having the right to import and export approved by the State Economic and Trade Commission. The company mainly engaged in importing and exporting of all kinds of lighting, lighting accessories, household appliances and other general non-state restrictive goods. And our annual trade amounted is more than 10 million dollars. Our staffs are all professional on foreign trade business, and familiar with foreign trade practices. We have our own foreign trade storage, also we have the whole quality assurance system throughout the process, from warehouse entry, testing, formal storage to shipment. Our tenet is" quality and service are the first". We have very good after-sales service system and can solve various problems of customers.
Bree Lighting will provide the best products and service. We focus on:
-LED flood light
(RGB/PIR/12V/24V/85-265V)
-LED tube light
(Waterproof T10/ Match with electronic rectifier/Dimmable/ Rotation/ Low voltage T8/ Uniform T5)
-LED down light
(COB / high power)
We sincerely welcome a wide variety of exchanges, cooperation and trade negotiations at home and abroad.
