Technical Parameters
-Standard length: 60cm, 120cm and 150cm.
-Rated input voltage: 100-240V AC, 50-60Hz, maximal input voltage 277V AC.
-PF (power factor): >0.91.
-CCT (color temperature) ranges: White 5500-6500K, Commercial White: 4000-4500K, Warm white: 3000-3500K.
-Much longer life than CFL tube: Min. 10 years (at an average usage of 8 hours per day).
- Custom-designed built-in driver, with reliable performance and long lifespan.
- UL & TUV certified circuit design.
- No risk of electric shock during installation.
- Compatible with existing inductive ballast fixtures, reducing installation cost and maintaining the warranty of the whole fixture.
Features:
-70%~80% Energy-saving over Fluorescent tubes.
-Solid State, high shock/vibration resistance.
-Work without ballast, Instant soft-start.
-No RF interference, No flickering or buzzing.
-Quick and easy installation to minimize retrofit costs.
-Minimum maintenance costs, generates little Heat.
-No Mercury and other hazardous materials, fully RoHS-compliant.
-Continuous operation for white LEDs (10 years for other colors).
-Rated to operate from -4° F to 104° F [-20° C to 40° C], perfect for environments with extreme climates.
-Epistar+Intermatix LED packaging solution, non patent-infringing.
-Modern design.
-Highly cost-effective.
-Completely insulated electrical design for maximum safety.
Factory Profile
1. Capetronix Ltd. Was founded in 2010, which is a leading manufactory on the indoor LED illumination, currently there are over 100 employees and a fabrication are of more than 2500 square meters.
2. Capetronix just focus on the LED tubes, LED bulbs, LED spots light, we desigh and manufacture, all of our products have 3 years warranty(tubes have 5 years warranty).
3. Every product undergoes multiple QC stages to ensure optimum performance and functionality.
4. Advanced and professional equipments are utilized to aid LED assemblies of LED tubes, array and various luminaire.
5. The equipments include SMT assembly, ato soldering lines, opto-electrical test devices, light and potical distribution analysis devices.
Service
1. Our goal is to help customers solve problems, to provide them with satisfactory products.
2. Fast deilvery: For samples 3 working day. For bulk order: 7-10working days.
3. Sample service is OK, but also we can help customers design or customize the products they want.
4. Professional sales team, engineer team, and good after-sales service. For any inquiries, we will give you the most professional answer within 24 hours.
Packing
1pcs in one inner box(white box, color box, blister packaging), 20pcs inner boxes in one carton. We can also do the packing according to your specific needs or sprayed with your own logo.
Delivery
Samples for 3-5 working days, bulk order for 7-10 working days.
|
Model Number |
Color Temperature
(K) |
LED Type
SMD |
LED Quantity
(pcs) |
Length
(mm) |
Voltage
(V) |
Power
(w) |
CRI |
Light Output
(lm) |
PC Cover |
|
T82C-30M0952X3-900 |
2800-3200 |
2835 |
52 |
600 |
100-240 |
9 |
>80 |
895 |
Frosted |
|
T82C-41M0952X3-900 |
4000-4500 |
970 |
|
T82C-55M0952X3-900 |
5500-6000 |
1001 |
|
T84C-30M18110X3-900 |
2800-3200 |
2835 |
110 |
1200 |
100-240 |
18 |
>80 |
1521 |
Frosted |
|
T84C-41M18110X3-900 |
4000-4500 |
1702 |
|
T84C-55M18110X3-900 |
5500-6000 |
1720 |
|
T85C-30M22130X3-900 |
2800-3200 |
2835 |
130 |
1500 |
100-240 |
22 |
>80 |
2017 |
Frosted |
|
T85C-41M22130X3-900 |
4000-4500 |
2132 |
|
T85C-55M22130X3-900 |
5500-6000 |
2269 |
Capetronix Ltd. was founded in 2010. Which is a leading manufactory on the indoor LED illumination. Currently there are over 100 employees and a fabrication area of more than 2, 500 square meters.
Capetronix main market is America, Europe; Of course we also have customers all over the world. Capetronix just focus on the LED tubes, LED bulbs, LED spots light, we design and manufacture, all of our products have 3 years warranty,
High-grade materials and state-of-the-art equipment such as auto soldering and SMT assembly lines are utilized throughout the manufacturing process of each of our products, which include LED tubes, LED spots, LED bulbs. The entire production process is supervised by professional personnel; Every product undergoes multiple QC stages to ensure optimum performance and functionality and is CE certified as well as RoHS compliant. Meanwhile our LED tubes has passed ETL certification, the LED spots has got GS certification.
We have a powerful R&D team, each month we have the products come out, and we also offer OEM &ODM sevice. Each one of our designs strictly follows the UL and EU electrical safety standards. Each lamp will pass the Chinese Government high voltages test. In most cases prototypes of custom designs can be submitted to customers in only 3 days.
Our excellent international sales and after-sales team will give the best service to our customers. All the email will reply in 36hours.
Focus makes perfect. Profession makes value.
