LED display(indoor p4)
Key Specifications/Special Features:
Pixel pitch: 4mm
Pixel arrangement: One chip with 3 colors(3-in-1)SMD
Module resolution(LxH): 32X32mm
Module size: 128X128mm
Cabinet size(WxHxD): 640X640X150mm
Density/: 62500
Driving method: 1/8
Refresh rate: >2000Hz
Brightness(Typical): 1500nit
Max power consumption (W/): 1200
Average power consumption(W/): 400
Control method: Synchronous/asynchronous Transmission
View angle: Horizontal: 140° , vertical: 140°
Color temperature: 3200K-9300K/Adjustable
Working temperature: Store -40° ~+85 deg. C/Working -20° ~+50 deg. C
Working voltage: AC110/220V± 15%
Video signal: S-VIDEO/RGB/RGBHV/YUV/YC/COMPOSITION etc.
Computer system: Windows7/Windows Vista/Windows XP
Life time: 50000-75000 Hours
Protection level: IP31
Out control dots: <0.0001
Features:
1) Types: Indoor LED display screen, wireless control,
2) Colors: Full color
3) High definition and high brightness; Long durability and high reliability
4) Advance video control system and Super input system
5) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal
6) Fit for various computer net
7) Standard connection socket
8) Easy installation, Low maintenance cost
9) Software for remote control of communication and scheduling
10) good heat emission capability
11) Customized design available
12) certification: CE FCC RoHS SGS.
13) Widely used in stage, concert, stadium, parties, bank, restaurant, station, shopping center, government, schools, and enterprise
Shenzhen DGX TECHNOLOGY Co., Ltd. is a high -tech enterprise which specialize in LED RD, design, production, assembly and so on, DGX locate in Bao'an district of Shenzhen China which is established in 2008 and has got 150 employees.
Our major products are full color LED outdoor/indoor display screen, LED tube light, LED indoor decorating lighting, scenery lighting and building lighting.
DGX 's culture soul is "morals, development and promise", all of our employees echnics management, quality and service are based on this culture soul.
DGX' s LED display and lighting products apply to night club, KTV, disco, theatre, building, plaza, square, TV station, all the lighting, entertainment, and advertisement field, we have got high reputation in these industry.
DGX apply Taiwan and CREE LED chip to ensure the vivid video effect and Technicolor, we have got many successful project, in every China province, Australia, EU, America, Africa and so on.
DGX is famous for high quality, fast response after service.
DGX develop all the business by international eyesight and developing policy to push LED industry in China and all the world, we are looking forward to wining the future with all global customers.
