Quick Details
Light Source: LED
Item Type: Light Strips
LED Light Source: 5050 RGB
Type: Flex LED Strips
Input Voltage(V): DC5V
Lamp Power: 10Watt/m
CRI (Ra>): 75
Color Temperature(CCT): -20~55
Working Lifetime(Hour): 50000
Lamp Body Material: Copper
Certification: CE, RoHS
Emitting Color: Changeable
Place of Origin: Guangdong, China (Mainland)
Brand Name: LF
Model Number: LF-FW5050RGB16GJT-2801
Product name: DC5V 32LEDs/m copper 5050 led strip light ws2801
LED chip: Epistar
Q'ty of lamp: 32leds/m
Q'ty of IC: 32IC/m
Q'ty of pixels: 32pixels/m
warranty: 2 years
Type of IC: ws2801
PCB Dimension: 5000mm*12mm*4mm
waterproof rating: IP40/IP65/IP67/IP68
Grey rating: 256
Packaging & Delivery
Packaging Details: | 5 meter per roll in static bags ,50 rolls per carton . |
---|
Delivery Detail: | 3~7 working days after confirm the order |
---|
DC5V 32LEDs/m copper 5050 led strip light ws2801
ws2801 addressable LED Strip, 32/36/96 LEDs, both white and black PCB, 5meters/roll.
1. Parameter
32LEDs ws2801;
DC5v, 10watt/meter;
32leds/meter, each LED separately control;
Epistar chip;
ws2801 IC, 32IC/meter (1 IC drives 1led chip);
ws2801 addressable LED Strip, 32/36/96 LEDs, both white and black PCB, 5meters/roll.
Pitch=31.25mm;
Grey scale: 256;
FPC Width: 12mm
FPC color: white, black
Both waterproof (IP65, IP67,IP68) and non- waterproof(IP40) are available
Full color changing
Warranty of 2 years
2. Different versions
ws2801 LED Strip |
Voltage | Max Power | LED resource | Qty of LED | Qty of IC | Pixels/M |
5v | 10w | 5050 RGB | 32/M | 32 | 32 |
5v | 11w | 5050 RGB | 36/M | 36 | 36 |
12v | 9w | 5050 RGB | 36/M | 12 | 12 |
12v | 24w | 5050 RGB | 96/M | 32 | 32 |
3. Protection rate
4. Control System
Small-scale control. 1000s, off-line working, can control MAX 2048 pixels
Large-scale control. 300K, on/off-line working, can control MAX 8192 pixels
Compatible with DMX512 and Arduino
5. Application
To create the Flexible LED Display
To create the Flexible LED Curtain
Indoor & outdoor decoration
Night-club, party, hotel backlighting
