Please read this manual before use the instrument
Shenzhen Kingpower Optoelectronic Technology Co., Ltd.
Professional supplier of LED wireless control system
Patent products, advantage:
KPR-SW6060-36W is a new LED color temperature adjustable optical flat light system with multi-functional RF wireless remote control.
The production is composed of wireless remote control, controller and LED flat light, It is our company's patented production with several obvious advantage and characteristics.
Products has two functions of adjustable color temperature and adjustable brightness, The software use smoothing treatment technology, adjustment is smooth and stable without Hopping, jitter and blinking.
Adopt unique warm white and cold white LED mixed drainage mode, During the process of color temperature adjustable, Lamps and lanterns color temperature adjustment, luminous evenly\no discoloration, stepless change, efficacy is very good.
3\With constant power regulation (the touch ring) and all power regulation (buttons )two adjusting color temperature way, save 50% of the light resources.
Production Specifications:
Size (mm) LED
Power(W) Input voltage
(V) Working voltage
(V) Working current
(mA) LED Quantity(PCS) Luminous flux (Lm) Color temperature range
Remote control range
(M)
598*598 36 100-240 DC24 900 360 2500-
2800K 2800K-
6500K 30
The outside diameter size: 598 mm * 598 mm
Luminous area: 558 mm * 558 mm
Into light way: Two side into light
Luminous source: 3014 SMD LED
LED quantity: 360 PCS
Luminous flux: 2500-2800 LM
Luminous Angle: 120 degrees
Color temperature: Cold white: 6000-65000 k, warm white: 2800-3200 k
Drive power: . Efficient PWM constant current drive;
The input voltage: AC100-240 v
Working voltage: DC24V
Working current: 900 mA/road, 2circuit
LED power: 36W
Total power: 42W
Color temperature regulation effect: From the warm white to white (2800 k - 6500 k hair effect), or back
Service life: In normal use condition, use time more than 40000 hours;
This product energy saving, high brightness, no stroboscopic phenomenon, no glare, no infrared,
King Power Optoelectronic Limited company is a high-tech enterprise committed to research on LED application technology and production. The company owns about 2500 square meter as production area, with 15 R&D staff, 18 QA and QC staff as well as 220 production staff. KPR has been committed to research on low-dissipation white color LED with two categories of products: High Power LED Lighting, LED Adorn Lighting.
Our major products: LED controller series, Color temperature adjustable LED panel series, LED panel l series, The human body inductive LED bulb series,
We have professional management team, and already passed ISO9001 and other certificates like CE FCC and RoHS. Our products have many advantages, like energy saving and environment friendly, high reliability, excellent thermal diffusivity on and on. All of the products got the test of Shenzhen Acadamy of Metrology & Quality Inspection, and got many international LED patent certificates.
KPR always holds good reputation, high quality, perfect technologic for our custom. In the spirit of honesty, pragmatism, innovation and excess, we are trying to be the lead of the world LED supply and make a little contribution for the developing and progress of human lighting.
