Model No. and Technical data:
Model No. | Pixel | Resolution | Brightness (CD/sqm) | Material | Size (mm) | Screen size (mm) | Weight (kg) | Power consumption(W) |
E-tank-P48890 | 4.8mm | 180 X 60 | 2200-2500 | Aluminum | 864 X 288 | 890 X 350 X 240 | 17.5 | Max: 400; Avg: 150 |
E-tank-P5825 | 5mm | 160 X 64 | 3000-3500 | Aluminum | 800 X 320 | 825 X 406 X 240 | 17 | Max: 420; Avg: 180 |
E-tank-P5985 | 5mm | 192 X 64 | 3000-3500 | Aluminum | 960 X 320 | 985 X 406 X 240 | 18.5 | Max: 500; Avg: 200 |
E-tank-P51045 | 5mm | 192 X 64 | 3000-3500 | Aluminum | 960 X 320 | 1045 X 406 X 240 | 19 | Max: 500; Avg: 200 |
E-tank-P51345 | 5mm | 192 X 64 | 3000-3500 | Aluminum | 960 X 320 | 1345 X 406 X 240 | 25 | Max: 500; Avg: 200 |
E-tank-51145 | 5mm | 224 X 64 | 3000-3500 | Aluminum | 1120 X 320 | 1145 X 406 X 240 | 20 | Max: 600; Avg: 250 |
E-tank-P51375 | 5mm | 256 X 64 | 3000-3500 | Aluminum | 1280 X 320 | 1375 X 448 X 240 | 23.5 | Max: 680; Avg: 300 |
1. | Brightness adjustment | 256 grade automatic, 8 grade manual, |
2. | Drive Mode | 1/816 or 1/15 or 1/8 scan |
3. | View Angle | 120 degrees(left and right view angle) |
4. | View Distance | 4-50 meters |
5. | Grey Scale | 65516 grades, |
6. | Display Colors | ≥281 trillion |
7. | Frame rate | 60 Frame |
8. | Refresh rate | 1200Hz |
9. | Control Mode | Asynchronized to computer |
10. | Screen Lifespan | >100,000 hours |
11. | Blind Spot Rate | ≤0.0002 |
12. | Operating Voltage | DC9-36V |
13. | Color Temperature | 6,500K±500 |
14. | Control way | 3G Wireless control |
15. | System Working Environment Temperature | -30ºC~+50ºC |
16. | System Working environment humidity | 10%-95%RH |
17. | System Operating Platform | WINDOWS(WIN XP, WIN 7, WIN 8) |
Inspection:
A. By in-house quality assurance dept and self certification.
B. Customer may also arrange for third party pre-dispatch inspection at our factory.
Warranty:
A. Two years from the date of dispatch against any manufacturing defects.
B. Annual, maintenance charges 8% of the total cost of the display and a separate AMC contract has to be entered into at the end of the warranty
period.
Traning:
One of your engineer will be trained free of charge at our factory on operation &1st level maintenance. All the expenses other than training have to be borne by the client.
RYHAM OPTOELECTRONICS has been recognized as one of the fastest growing and professional supplier in LED industry since it's foundation in 2008 in shenzhen, China.
We are supplying a completely integrated solution to the civil construction facilities, advertising, rental, live concerts and stage show design. Our products covers LED electronic information board, indoor and outdoor full color LED display. Nowadays, portability and mobility are become more and more important to the market. So RYHAM develop innovative completely soft LED display and Flexible LED curtain screen. These series products are greatly welcome by customer.
Ryham is dedicated to provide efficient, affordable and creative product and service to cater diverse expectations. We are committed to continuous improvement, training and educating our staff, listening to our customers and producing high value products for our customers. During last few years, RYHAM screens grow in Asia, North Africa, Middle East, North America, South America and vast Europe.
It's our management philosophy to create successful relationships with our customers with our credibility and sincerity. Excellence and innovation is always our pursuit. Ryham holds the belief that mutual business is a long term friendships only if we keep our promise to clients. Our guarantee is to achieve your objectives and exceed your expectations.
If you expect outstanding styling design that'll bring LED vision to your life, if you demand trained & practiced service behind you---Ryham is your first choice! - See more at: http://www.ledtaxidisplay.com/about.html#sthash.iTxm1pPD.dpuf
