CE RoHS UL Certificate Waterproof LED Strip Light
SMD2835 Constant current Waterproof LED strips
Constant current design, no voltage drop. The same brightness of each LED on the reel. No risistors, Maximum reduce product failure, good option for everywhere need longer length and same brightness.
Features:
1. SMD 2835 LED as lighting sources.
2. LED Q'ty: 300pcs.
3: Working voltage: DC24V.
4: Max. Current: 40mA/ LED.
5: Cuttable length: Every 6 leds.
6: IP20, IP54, IP67 for option.
7: Color like Red, Blue, Yellow, Green are available.
8. Working temperature and Storage temperature: 0º C - 40º C
Application:
1. Decorative lighting for exhibition shelves, advertising light box and hotel etc;
2. Backlight for edge lighting/signage;
3. Holiday decorative lights, residential and outdoor lighting;
4. Bridge, garden, road and car lighting etc;
5. Long-distance project but with inconvenient wiring;
Note:
1. Before use, first check the power supply used in compliance with GL-FB LED flexible light of the power requirements;
2. Each roll ask for independent power supply; Not to use of multi-volume series use
Other:
General Lighting Electronic Co., Ltd. All rights reserved. No part of this photo may be reproduced, in any form or by any means, without permission in writing from General Lighting Electronic Co. Ltd.
|
Part Number |
Input Voltage |
LED Type |
Power |
Tc(K)/nm |
Strip Width |
PCB Color |
Luminous
Flux (0.5M) |
Continuous
length |
Cuttable
Length |
Lifespan |
|
GL-24-F321A-B |
24VDC |
2835 |
60W |
5700K-6500K |
10mm |
white |
540lm |
10M |
Every 6 Leds |
30,000H |
|
GL-24-F321B-B |
24VDC |
2835 |
60W |
5700K-6500K |
10mm |
white |
540lm |
10M |
Every 6 Leds |
30,000H |
|
GL-24-F321C-B |
24VDC |
2835 |
60W |
5700K-6500K |
10mm |
white |
540lm |
10M |
Every 6 Leds |
30,000H |
|
GL-24-F321F-B |
24VDC |
2835 |
60W |
5700K-6500K |
10mm |
white |
540lm |
10M |
Every 6 Leds |
30,000H |
|
GL-24-F321N-A |
24VDC |
2835 |
60W |
5700K-6500K |
10mm |
white |
600lm |
10M |
Every 6 Leds |
30,000H |
Note: F321--PCB code; The letter behind F321- Waterproof types; A- Waterproofing casing; B-Silicone;C-Heat shrinkable tube;F-Silicon dripping; N-Non-waterproof.
|
Part Number |
Size(mm)/reel |
Light Tr-
ansmitt-
ance |
Light
Angle |
CRI |
Wiring Mode(un-
ilateral/bilateral) |
Accessories |
IP |
Operating
Temperature |
|
GL-24-F321A-B |
5000x12mm |
90% |
120° |
Ra>70 |
5.5mm DC Connector |
Plug/Glue/Wire |
IP67 |
0ºC - 40ºC |
|
GL-24-F321B-B |
5000x12mm |
90% |
120° |
Ra>70 |
5.5mm DC Connector |
Wire |
IP67 |
0ºC - 40ºC |
|
GL-24-F321C-B |
5000x10mm |
90% |
120° |
Ra>70 |
Red & White Pins |
Wire |
IP67 |
0ºC - 40ºC |
|
GL-24-F321F-B |
5000x10mm |
90% |
120° |
Ra>70 |
Red & White Pins |
Wire |
IP54 |
0ºC - 40ºC |
|
GL-24-F321N-A |
5000x10mm |
90% |
120° |
Ra>70 |
Red & White Pins |
Connector |
IP20 |
0ºC - 40ºC |
