P16 Outdoor Full Color LED Display /led screen/led sign/LED video wall
Ability
Integration of industrial chain
Advanced Technology
Large-scale, standardized Production
Custom Design
Cost Control
Qualification
2010 Shanghai World Expo official sponsor
2012 Asia Game LED Display supplier
19 years design and manufacture full color display experience
Classic projects all over the world that would be time-tested
Partner for Guangzhou Asian Games, Shanghai World Expo, Beijing Olympic Games, China-Asian Expo and Boao Asian Forum.
P16 outdoor full-color high-contrast LED display |
Item |
Details |
Parameters |
Pixel |
Physical |
16mm |
Pixel Configuration |
1R1G1B |
Module |
Module resolution |
16*16 pixels |
Module Size |
256*256mm |
Cabinet |
Physical resolution |
64*64 pixels |
Cabinet Size |
1024*1024mm HxW |
Physical density |
4096 pixels/cabinet |
Module quantity |
16pcs=4(h)*4(w) |
Material |
steel |
Weight |
55 kg Approx |
Power supply(5V60A) Quantity |
4 pcs |
Average power consumption |
410W |
Max power consumption |
1220W |
Electricity
parameter |
Brightness |
9000 nits |
Brightness adjusted |
100 grade by software or by Auto-optic induced |
Color processing |
8 bits |
Display color |
16 millions |
Color temperature(k) |
7200k |
Physical density |
3906 pixels/per square meter |
Whole display flatness |
≤ 1.2mm Juncture |
Best view distance |
9-65m |
Best viewing angle |
H≥100° V≥50° |
Storage temperature |
40 degree -5 degree |
Working temperature |
20 degree -50 degree |
Driving Method |
Constant driving current Scan: static |
Refresh frequency |
up to 300Hz |
Frame rate |
75Hz |
Humidity(RH) |
10%-90% |
Protection grade |
Front IP65, Rear IP54 if not specified |
Working voltage |
DC 5V |
Power supply |
AC 110V ±10% / 220V ±10% |
Average power consumption |
400W/M2 |
Max power consumption |
1200W/M2 |
MTBF |
8,000 hours |
Screen lifetime |
100,000 hours |
Control
System |
Control System |
Linsn |
Signal Interface |
DVI |
Communication distance |
CAT5cable:≤100m Fiber Cable:≥500m |
Signal transfer mode |
dot to dot synchronized with computer monitor |
