Feature:
1. Compact and lightweight, easy to control
2. 4pcs high brightness 10W RGBW 4in1 LEDs
3. Pan/Tilt invert option, Fan cooled
Specification:
Input power:AC100-240V 50/60 Hz
Power consumption :70W
LED: 4x10w (RGBW 4 in 1)
DMX channel: 9/16 channel
DMX connector : 3 pin XLR
Control mode:DMX512/Master-Slave/Auto run/sound
Movement:Pan/Tilt:X axis540degree ,Y axis 180 degree
Display: LCD display
Tiptop environment temperature: 104°F(40°C)
Variable electronic strobe
Variable electronic dimmer(0-100%)
Pan/tilt invert option.
Fan cooled.
product size : 210 ×135×230mm
N,W : 3kg
DMX Channel:
| 16CH | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
| Function | Pan movement | Pan Fine | Tilt movement | Tilt Fine | Pan/Tilt Speed | Pan movement | Pan/Tilt Macros | Pan/Tilt Macro Speed |
| 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
| Master Dimmer | Shutter/Strobe | Red 1 | Green1 | Blue 1 | white 1 | Color functions | Color change
/Fade Speed |
9CH | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
| Function | Pan movement | Tilt movement | Master Dimmer | Strobe | Red 1 | Green1 | Blue 1 | white 1 | Special function |
