Specification for 50W LED high bay light
Model: SW-HB04-W50
Pwer: 50W
Input Voltage: AC90-265V, 50/60Hz
LED brand: BridgeLux
Power Facto: R >95%
Total Harmonic Distortion: <15%
Color Temperature: 2700-4000K/4000-6000/6000-7000K
Color Rendering Index >78Ra
LED Lighting Efficiency: 100-110lm/w
Working Environment Working temperature: -40° C~+55° C
Working humidity: 10%-90%
IP Rating: IP54
Working Life >50, 000 hours
Body &Shade Material: Aluminum alloy
Features:
1. Applied wide voltage: AC85-265V, 277V.
2. Bridgelux LED chip, 100-110lm/w.
3. CE RoHS, UL approvaled driver.
4. Special design for heat sinking, ensuring safe working temperature and long life.
5. True color rendering with optional light colors.
6. Life span: >50000 hours.
7. Certifications: CE, RoHS.
Application:
Workshops, factories, storehouses, toll stations, gas stations, supermarkets, exhibition halls, gymnasium, and some other places where need industrial lighting.
|
Input Voltage |
AC85V-265V |
|
Freqency Range |
50Hz--60Hz |
|
Tatal Harmonic Distortion |
≤9% |
|
Power Factor |
>0.98 |
|
Power Efficiency |
>89% |
|
LED Working Voltage |
DC30-36V |
|
LED quantity |
1Pc |
|
LED consumption |
50W |
|
System Consumption |
57W |
|
LED luminous |
100-110LM/W |
|
Lamp's Efficiency |
>85% |
Shenzhen Snoowel Technology Co., Ltd is a professional manufacturer and exporter of LED lighting products, including high power LED street lights, outdoor LED flood lights, LED high bay lights, LED tunnel lights, T8 LED tubes, LED bulb lights, LED spotlight, LED down lights, LED ceiling lights, LED panel lights, LED pl lamp etc.
Since our establishment, we have been focusing on the development of eco-friendly & energy saving products, and never forgot to make them better. Now we have first class engineers and technologists, first class labs, and first class equipments and testing machines, which guaranteed that the products from our factory will be impeccable. With most advanced Auto "ASM" machines, Auto Light and Color-division machines imported from Germany and USA, we have improved our production efficiency and products quality dramatically. Now our multi chip products have won many rewards, and successfully installed in many big projects in both China and overseas. Snoowel Technology firmly follows the procedure of ISO9001: 2000, and always persists in human-based management, human-based design. Our goal is to creat a better lighting world at lower cost.
We welcome the inquiry from customers in any part of the world, and will always offer best products at most competative prices. Meanwhile, we could work together with our all of our customers, and find best solutions for your lighting projects.
