LED display
1. The led display is very popular in advertising field, widely used in waiting room of station, meeting room, indoor led video wall. Lobby, club, exhibition, cinema, etc. Synchronization with control PC, reproduce the same time as the videos played on the PC.
2. Supplied by Silan of china & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display system.
3. Easy and simple installation interface and user friendly software to ensure that customers use easily
We have outdoor type:P5, P6, P6.67,P8,P10,P12,P16,P20 ETC. indoor type: P2, P2.5, P3, P4, P5, P6, P7.62, p4.91, P10 ETC.
Which one are interested in, pls feel fee to contact!
P6 indoor full color led display
|
Items | P6 indoor full color led display board |
Pitch size | 6mm |
Module size | 192mm*96mm |
Module pixel(dots) | 32*16 |
Pixel configuration | 1Red, 1Green, 1Blue SMD 3-in-1 |
LED chip | Silan/Cree/Nichia |
Color scale | 65536degree/1.07 billion colors |
Pixel density | 27777pixels/square meter |
View angle(H/V) | 120/120degree |
Brightness | ≥ 1200cd/sqm |
Brightness adjustment | 100level automatic or manual |
View distance | 5--80m |
Power consumption | 100-1200W/sqm |
Net weight | < 45kg/square meter |
Operating temperature | - 25° C~+60° C |
Operating humidity | 10%- 95%RH |
Life time | ≥ 100, 000hours |
Out of control dot | ≤ 3/10, 000 |
Whole Display Flatness | ≤ 1mm Juncture |
Exchange frame speed | > 150frames per second |
Refresh frame frequency | 600Hz |
Control distance | Cat. 5: 120m (without repeater), single mode fiber: 20km, multi mode fiber: 500m |
Power | 110V/220V± 15% 50Hz |
Operating system | Windows98/Me/2000/Xp |
Drive mode | constant current driving, static scan |
Display mode | VGA640X480- VGA1600X1024 |
Protections for outdoor display | IP65 for front, IP64 for rear |
Maintenance way | rear access, haging installation |
Accepting signal | PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite Video; SDI |
FAQ:1. Diversified products :
Varieties of models for outdoor/indoor LED display screens,and customized cabinets available,meet all requirements and win more profits for customers.
2. Experienced&Professional:
10 years manufacturing experience on LED displays, professional workmanship & design.
3. Best raw materials:
High quality,high brightness and long life span.
4. Competitive price:
100% factory price,competitive and reasonable price.
5. Strict quality control:
100% testing before packing , make sure our quality before delivery.
6. Quality gurantee:
Life span of LED display screens is more than 100,000 hours All our LED displays have CE,FCC,RoHS certificates.
7. Prompt &Professional service :
Any inquires will be replied within 24 hours in working days and you'll get helpful suggestions from us.
Guangzhou Qichuang Electronic & Technology Co., Ltd. locate in Guangzhou, China, found in 2003. It is a professional manufacturerer of LED displays screen, and the CEO of Qichuang is a skillful LED display expert before he established the company.
Qichuang Technology specializes in all types of LED display screen, including indoor and outdoor LED displays, single color, dual colors, RGB full-color displays. As one of the professional LED Displays manufacturers of China, we combine products producing, technology support, marketing, installation and after-sales service together so as to meet the demands of market, make every client satisfied.
LED displays from our company have been widely used in a variety of sites like railway station, bank, hospital, office building, outdoor advertising board, airport, post office, gymnasium and so on. They play an important role for enterprises' spreading and service convenience, and become very popular in every corner of the world.
Technical traits of LED displays:
Vivid and exact picture, minimum noise, advanced test equipment, support any PC operation system and play a variety of information like video, word, flash, music, clock, graph etc. Easy to install and dismantle.
Our Commitments: First-class quality, excellent technology support, best after-sales service.
