Solar lamp instructions
YF-168\YF-159 Multifunctional solar lamp is super capacity, high brightness, elegant shape. Select this product equal to choose health and light. In the meanwhile, it can make your work, life and travel more convenient
Operating instructions
1, THe outer solar charging solar panels can be placed in a sunny place, when charging, the charging instruction is red. Do not have something blocking the solar panel.
2, AC charging, the charger insert into the DC, and plug put in the power, the LED on the AC charging instructions for the red, full of the LED is green, charger may be a bit hot while charging, that is normal.
3, Switch have 5 level, the first level for low brightness, lighting time is relatively longer. The higher level, the higher brightness. The fourth level for highest brightness and the lighting time is relatively shorter. The fifth files is closed(no voltage output)
4, The item has USB, can charge mobile phone.
TECHNICAL SPECIFICATION
Material: ABS shell
Battery: Lead acid battery, 4v 5000mAH
Light source: High brightness LED, 1w
Solar panel: 6v 2w
Charge time: 8-10hours charged by AC current, 13-15hours charged by solar energy
Lllumination time: 80 hours for settings I, 40hours for settings II, 25hours for setting III, 16 hours for setting IV
MAINTENACE
1, Use cotton cloth with some alcohol to wipe the parts of the unit
2, Do not use some hard or volatilized chemical to wipe, because it will damage the unit
3, Do not use other battery in order to protect the unit
4, Do not open the unit if you are not professional
Production function:
1, When charging for the light fully by solar panel, the electricity will be cut off automatically, you don't need to worry about this
2, The light charging for the mobile phine, when fully, it will cut off automatically
Production quality guarantee:
Company's products follow the company QB/YF-03-2004, belong to the company's products quality problems, the warranty are 3 month from the date of purchase. (Non-proper use which cause damage the products burnt are not within warranty)
