Power: 9.6W/M, 14.4W/M
Input Voltage: DC12V
Length: 1010MM
LED QTY/Meter: 120
Color: Y/R/B/G/W
Working Temperature: -40--+50C
Storage temperature: -50--+60C
Description:
Installation type: Mounting
Aluminum profile: #6063 alumium, anodized aluminum
PC Cover: Diffuse/Clear/milky/V1 fire resistant rate
Ending cap: White PC with hole; V1 fire resistant rate
Matched FPCB: 10-12mm Width
PC cover
PC cover V1 fire resistant rate
Cpver types: Diffuse/clear
Technology: Extruded technology
LED Flexible Strip
Material: Rolled copper
Technology: Anti-oxidation technology
Aluminum Profile
Material: 6063-T5 aircraft Aluminum
Technology: Anode argentous oxide
End Cap
PC cover V1 fire resistant rate
Technology: Injection technology
LED Strip Recommend
BQ00-3528*120Hy12-W10-IP20
BQ00-3528*120Hy24-W10-IP20
BQ00-3014*120Hy24-W10-IP20
BQ00-3014*120Hy12-W10-IP20
Color: R G B Y W
Application
1. Ceiling
2. Corridor
3. Auxiliary and decoration illumination
Installation Instruction
1. Drill a hole in the fluting for M3 screw.
2. Fix M3*15 Self-tapping screw
3. Place led flexible strip in aluminum profile.
4. Place PC Cover onto the aluminum profile, smear the ending cap with silicon glue.
5. Put the ending cap with silicon glue into aluminum and wait for dry.
Shenzhen Banq Technology Co., Ltd., is a professional LED manufacturer with strong capability in R&D, Production, Marketing and customer service. We have a variety of products, which can be classified in two catagories:
First is LED general illumination lights which including LED bulb, LED tube, LED strip/Ribbon, LED spotlight, LED down light, LED SMD spotlight, Auto light, wall washer, as well as LED module. Second is indicating LED for different applications which including high/low power LED series. Super flux LED (Piranha) series, SMD LED series, and super-bright through-hole LED series. Our products are widely used in General Illumination Industry, Auto Industry, Electronic Display Industry and signal Electronic iIndustry etc.
Established in 2002, with a total area of 16000 square meters, BANQ has about 1000 well-trained employees. With our dedicated staffs and rich experience in LED field, we can quickly respond to customer needs, providing customized products and services to help customers succeed. At present, we export 90% of our prodcuts Europe, North America, and some other countries.
"Quality First, Customer Paramount, Service Uppermost! " is our principles. In order to make the life of modern people more wonderful, BANQ is willing to form a close ally with customers through our superior LED products, excellent and value-added service.
