SPECIFICATIONS
-- Light box for advertising to illuminate your brand
-- High quality Electropheresis treatment for aluminum frame
-- Power consumption : 10-20W per square meter
-- Thickness : 28mm , board width : 40mm
-- Clasic colour : White powder coating
-- PS sheet as front panel
-- Snap clip open the frame , front loading the graphics ,easy to change
-- High quality Tube light source or SMD LED light source
-- Guarantee :2 years
DESCRIPTION
Electropheresis or anodised treatment for aluminum frame to ensure a better quality and a more elegant looking ,different colours are available
Snap open the frame ,easy to change the graphics
Light output : 2000-3000 lux ( Max. 8000 LUX )
Long life span with more than 50,000 hours
Laser engraved LGP with even brightness and less aging
Silk screen printing LGP can keep a good quality as well as saving some cost
Colours : silver / black anodised or electrophereis ,other RAL colours are available .
Different size can be customized , the biggest size can be 2m * 3m
Application : Bank ,hospital ,Gas station , railway station , bus station , shopping mall , chain store ,supermarket etc.
PACKAGE
Item |
Frame size/mm |
Viewing size/mm |
Thickness/mm |
Flim size/mm |
Packaging size/cm |
Volume/m 3 |
Gross weight/kg |
FS-
S04 |
LED |
B1 |
1038*755 |
968*685 |
28 |
100*707 |
114*9*85 |
0.09 |
12.5 |
B2 |
539*755 |
468*685 |
707*500 |
84*9*65 |
0.05 |
6.7 |
A0 |
1227*889 |
1157*819 |
1189*841 |
134*9*102 |
0.12 |
16.6 |
A1 |
632*889 |
562*819 |
841*594 |
100*9*77 |
0.07 |
9.4 |
A2 |
548*642 |
388*572 |
594*420 |
73*9*57 |
0.04 |
6.6 |
A3 |
335*468 |
265*398 |
420*297 |
58*9*46 |
0.02 |
2.8 |
A4 |
345*248 |
275*178 |
297*210 |
50*5*30 |
0.01 |
3.6 |
|
|
