9W COB MR16 LED Spotlight
Type: 9W
Voltage: AC85-265V
Base: GU5.3
Emitting angle: 60degrees
Bulb lifespan: 50, 000 hours
Colors: Warm white, cold white
Temperature 0 to 45Degrees
CRI: RA>0.80
Size: Diameter: 49.5* 111mm
Certification: CE, RoHS
MR16 COB LED Spotlight Product features
1. Fully compatible for traditional MR16 halogen spotlight
2. Compatiable to electronic transformer
3. No ultraviolet and infrared ray, and no mercury.
4. Greatly reduce energy consumption and operating cost
5. With the aluminum substrate have good thermal radiation.
6. Long span life
7. Low lumen depreciation
8. Full range of colors
9. Brighter than traditional fluorescent lamps
Application:
Spot lighting
Architectural Lighting
Display case accent
Reading Light
Biological lighting
Installtion:
1. Remove the non-functioning bulb from its socket. This can usually be done by removing a retaining clip with your fingers, then removing the UV-coated circular glass pane. After the UV glass pane is removed, you can pull the bulb and wiring harness from the housing. Remove the bulb by pulling it away from the harness with one hand while holding on to the harness with the other.
2. Insert the new bulb by pressing the two exposed pins on the rear of the bulb into the two holes in the harness.
3. Replace the bulb and harness into the housing, then replace the glass pane and retaining clip.
Notice:
MR16 LED spotlight is 12V only
It requires LED driver( transformer) to run it. Please choose right power supply to match the product
Do not see the light sources by eyes directly
Please make sure the power is off before use
Please do not touch the product surface when it is lighting
Indoor use only
Please do not put the product as children toy
