90-120W High Power LED Street Light Series, LED light used for street light, sports park, tennis court, high way etc
Get 26 patent certificates, including Chinese utility model patent certificate 17, the Republic of China (China Taiwan) 8 new patent certificate, a patent certificate of the United States, covering the thermal structure technology, nanotechnology, power supply and so on. The following list is only obtained patents in 2012
The LED module has Nanometer surface coating and hollowed structure, utilize the Natural convection and Heat pump effect which can increase the dissipation capacity. Finally, the dissipation capacity can reach to 2.0 W/in ² .
For vertical lighting, we measure and calculate light angle for each lamp, distribute light through the lens or other different ways, such as keeping LED lamps and light source and the angle the same, directly reduces wasting light source, can improve the use efficiency of light.
The LED light module combination lamp is light-weighted (LED module 800g), the whole light's weight is reduced, so shaking in the air is reduced.
Application:
Widely used in Square, Highway, Garden, Traffic Road and Street, Sport Venues
Feature
Ultra-thin heat-dissipation module and super power-saving technologies
Unique innovative light engine module design
High-illumination efficiency and long lifetime, accomplishing energy-saving and carbon-reducing effectively
Optimum optical design with no scattered light and comply with anti-glare regulations
Optical Spec |
|
|
|
|
|
|
Item# |
|
LT-R03-T1-72 |
|
LT-R03-T1-90 |
|
LT-R03-T1-120 |
LED Qty |
|
72×1W LED |
|
90×1W LED |
|
72×1.5W LED |
LED Color Temperature |
|
2700K-3500K/4000K-5000K/5000K-6500K |
|
2700K-3500K/4000K-5000K/5000K-6500K |
|
2700K-3500K/4000K-5000K/5000K-6500K |
LED Efficiency |
|
110-140lm |
|
110-140lm |
|
110-140lm |
Lamp Efficiency |
|
70-90lm/W |
|
70-90lm/W |
|
70-75lm/W |
Illumination |
|
5040-6480lm |
|
6300-8100lm |
|
8400-9000lm |
CRI |
|
70-85 |
|
70-85 |
|
70-85 |
Beam Angle |
|
120°×45°/120°×60°(elect) |
Electrical Spec |
|
|
|
|
|
|
Operating voltage |
|
AC100-240V 50/60Hz |
|
AC100-240V 50/60Hz |
|
AC100-240V 50/60Hz |
Power Factor |
|
>0.9 |
|
>0.9 |
|
>0.9 |
Power Consumption |
|
72W |
|
90W |
|
120W |
IP Rating |
|
IP65 |
|
IP65 |
|
IP65 |
Operating Temp |
|
-40~50 |
|
-40~50 |
|
-40~50 |
Operating Humidity |
|
10~90RH |
|
10~90RH |
|
10~90RH |
Net Weight |
|
5±0.2KG |
|
5±0.2KG |
|
5±0.2KG |
Limited Warranty |
|
50000h |
|
50000h |
|
50000h |
Dimension(mm) |
|
L519×W213×H118 |
|
L519×W213×H118 |
|
L519×W213×H118 |
