Feature:
A)High quality light source, The attenuation of high power LED light source is less than 5% by 5,000hrs aging test under temperature 50 degree Celsius, high luminous efficiency of single LED.
B) Superior raw materials.Made of high quality aluminumwhich helps heat dissipation.
C) Professional thermal management.
D) High temperature resistant housing for safety.
E) No RF interference & electric wave resistant.No mercury or lead, No Mercury and ultraviolet ray, No danger of broken glass.
F) With CE, ROHS approvals & 3 years warranty.
G) Instant start, no flickering & humming.
H) Energy saving up to 84%.
I) Built-in high efficiency constant current driver, Wide Voltage AC85-264V 50/60Hz input, worldwide application.
J) Easy to install, a perfect replacement for traditional bulbs.
K) 5 years lifespan (LED), 10 times more than traditional bulbs.
L) Strict quality control, 72hrs aging and complete inspection before shipping
M) Solid-state, high shock resistant, strong packaging, convenient to transportation.
N) Isolated driver ensures high safety.
Installation:
A) Before installation, please make sure the power switch is turned off.Hold the light bulb securely, insert light bulb
Screw base into the lamp socket and tighten it in clockwise direction.
B) Make sure the light bulb screw into the socket correctly.Turn the power switch on, and the light bulb should light up.
Application Note:
A) Please make sure the working voltage is correct.Incorrect voltage may lead to damage of the light bulb.
B) Do not use this light bulb in the outdoor environment, emergency exit facilities, or emergency lighting facilities.
C) To avoid electric shock, after fitting the light bulb and switch on the power, please do not touch the metal area of the screw base.
D) Before open the package, please check for any damage on the package caused during transportation.Please inform the supplier for replacement if any damage on the package is found.
E) For product safety, please follow the instruction manual.
F) Before installation, please make sure the installation area can endure 10 times of the light bulb weight.Light bulb should be installed in the flat surface, an environment without vibration, swing, and threat from fire.
G) During the light bulb operation, the case may reach 55°C.Light bulb should keep away from temperature sensitive equipment.After switch off the power, please wait for 30 minutes, before uninstall the light bulb.
H) This is a semi-conductor lighting fixture, and it is very sensitive to the ambient temperature.If the ambient temperature is above 55°C, the life span of the light bulb will be shortened.Hence please keep the light bulb away from the heat source.To maximize the life span of the light bulb, please maintain the working temperature at between -20°C to 25°C, and make sure the working environment has good ventilation.
I) Please do not switch the power on and off continuously within a short period.This will lead to the damage of the lamp.
J) Under emergency situation, please do the following:
(a) Please check the input voltage.
(b) Please check the switch is functioning normally
(c) If the lamp still cannot light up, please inform the professionals for further examination.
Warranty:
3 years warranty replacement from date of purchase is offered for all LED lighting products from Optoleder.
Warranty Terms :
1, Please provide the proof or pictures of faulty product during warranty period, or return the faulty products if needed.
2, Any warranty claim for replacement from the date of purchase is only valid if used correctly.
Trade Terms
1.Payment:T/T , 30% deposits before production, 70% balance to be paid before delivering
2.Production lead time 7-15days
3.Shipping freight are quoted under your requests
4.Shipping port:Shenzhen, Mainland China
5.Discounts can be offered based on order quantities
|
7W LED BULB |
|
Model |
GH-BULB-7W |
|
Input Voltage |
AC100V-240V |
|
Freqency Range |
50Hz--60Hz |
|
Power Factor |
0.7--0.8 |
|
Power |
7W |
|
Base |
E27 |
|
LED Brand |
Epistar |
|
Beam angle |
180° |
|
Color Temperature |
WW |
3000--3500K |
|
NW |
4000--4500K |
|
PW |
6000--6500K |
|
Total Lumen output |
560-595lm |
|
Color Rendering Index |
Ra≥80 |
|
Working life-span |
50000Hrs |
|
NW |
95g |
|
GW |
123g |
|
Color of lamp shell |
White |
|
Certificate |
|
|
Inside box size |
66*66*110mm |
|
QTY/ carton |
20pcs/ box ; total: 6 boxes *20 = 120pcs / carton |
|
Carton Size |
57.5*35.5*38.5cm |
Shenzhen Optoleder Technology Co., Ltd., established in 2010, is an innovative and national high-tech LED lighting and LED package manufacturer in Shenzhen of China, where it is the LED supreme headquarter. Optoleder is going to be a top commercial LED lighting provider in the coming future with the support from our partners and customers based on our efforts.
Now we have four divisions, LED lighting division, LED package division, Hardware Division and Power Supply/Drivers division. Optoleder is developing into a top commercial LED lights provider of a total solution at a high and stable speed. A professional management team and the powerful production of 25, 000 square meter area with automatic and advanced production lines give our partners and customers best service and products under the strict quality control process. Mr., Zeng Xian Ping, who is Chairman of Optoleder has nearly 20 years experience of management for optics and chemicals company. He is the leader of this positive and creative team of Optoleder.
Main Products:
LED Bulbs, LED Spotlights, LED downlights, LED Tubes and LED panel lights, with CCC for China, ETL and UL for America, TUV, CE, RoHS for Europe and Asian countries, SAA for Oceania, and PSE for Japan, are well accepted in the world.
Innovative R&D Team:
Head of Engineering Department for LED lighting has more than 15 years of electronics and optics experience. This team is efficient and diligent for new technology of LED lighting, especially for dimmable technology. Now triac dimmers are popular in the world. Few manufacturers can make good compatible dimmable bulbs and spotlights, while we have a good solution of this type of dimmable tech. Compatibility and function are top in LED lighting field.
Passionate Sales Team,:
We sales team, with the average age at 25 years old, are passionate about LED lighting and positive to our sales jobs. We promise that we give customers best service and fastest response speed at a 24-hour hot line. Now we offer Chinese, English, Russian, Japanese, and Spanish speaking of considerate sales, which will let you feel our passion and profession.
Efficient Production Team:
Optoleder has more than 20, 000 square meter workshops with advance equipment and machines, which are imported from USA, Germany, Japan etc. Production workers have to pass the strict operation and training exam before working. All technicians have at least bachelor degree of technology with years of working experience. Now Optoleder is certified by ISO9000 with good management system.
Quality Control Process:
Optoleder's lighting products go through a full and strict quality inspection process with aging test of 24 hours and high and low voltage test after production, then they will leave the factory to partners and customers with good package and instructions.
Warmly welcome all fields of friends to visit our company and negotiate trade.
